Haier HDW100SST HA Parts Manual page 9

REF PART
34 H012G2160241
35 H012G4050157
36 H0120202777
37 H0120202779
38 H0120202780
39 H0120300947
40 H0120201019
41 H0120202056
42 H0120505219
43 H012G6050040
44 H012G5060020
45 422680P
46 H0120400440
47 H012G2160197
48 H0120201008
49 H012G6010009
50 H012G1450902
51 H012G8040038
52 H0124000661
53 H012G4050158
54 H012G1040020
55 420667P
56 H012G2140061
57 H012G6050043
58 H012G2140067
59 H012G8050084
60 H0120202556A
61 H012G1040020
62 H0124000163
63 H012G4050150
64 H012G8060036
65 H0120203065
66 H012G4050151
67 H0120201292
68 H012G1040014
69 H0120200949
70 H012G1040012
71 H0120201009
72 H0120202778
73 H012G4050152
74 H012G1040028
75 H012G2160193
76 H012G4050153
77 H0120201006
Continued next page
RETICULATION AREA
OUTER DUCT
O-RING GASKET
UPPER SPRAYER BASE
INNER DUCT COVER
INNER DUCT SEALING
DIVERSION PIPE SEALING
UPPER SPRAYER ASSEMBLY
SUPPORT FOR FLOAT
FLOAT FOR ACQUASTOP
MICRO SWITCH
1-WAY SOLENOID VALVE
HOSE INLET LONG (2M) PKD
POWER SUPPLY CABLE
AIR BREAK NOZZLE
BREATHER RING NUT
THERMO LIMITER
BUSH FOR FASTENING OF HEATING ELEMENT THERMIC SWITCH
ELASTICITY RETAINER
DRAIN PUMP
O-RING GASKET
BAND
GUIDE DRAIN HOSE
DRAIN HOSE
WATER-LEVEL PRESSURE SWITCH
PRESSURE SWITCH TUBE
BAND
INSULATED TUB INLET
BAND
THERMO LIMITER ASSEMBLY
O-RING GASKET
DENTIFORM RETAINER
WATER GUTTER
CUP GASKET
RING NUT FOR CUP FASTENING
MICROFILTER (POLYESTHERE)
INNER FILTER SCREEN
PLANE FILTER SCREEN
EXTRACTABLE GLASS-FILTER
INNER DUCT
RUBBER COUPLING
BAND
LOWER SPRAYER BASE FIXING PIECE
O-RING GASKET
RING NUT FOR LOWER SPRAYER FASTENING
DESCRIPTION
9
61505
