- Page 1 TuneCommand ™ for iPod ® Wirelessly control your tunes anywhere User Manual F8Z024ea P74852_F8Z024_uk.indd 3 29/9/05 4:10:24 pm...
- Page 2 P74852_F8Z024_uk.indd 4 29/9/05 4:10:24 pm...
- Page 3 Designed to let you roam and play your tunes from virtually anywhere in your home, the TuneCommand for iPod from Belkin delivers the flexibility and convenience that iPod users desire. Using wireless radio frequency technology, TuneCommand works from up to 120 ft. / 37 m. away from your stereo.
-
Page 4: What's In The Box
What’s in the Box TuneCommand Receiver for Multi-Clip iPod Surface-Mount Hook TuneCommand Remote Battery (model CR 2032) Transmitter Lanyard Adjuster Lanyard What’s in the Box P74852_F8Z024_uk.indd 2 29/9/05 4:10:25 pm... - Page 5 Operating Instructions STEP 1 - TuneCommand Receiver Setup 1. Power on your iPod. Then, plug the TuneCommand Receiver into the iPod device’s remote/headphone connector (Fig. 1). The Receiver powers on automatically and its green light blinks three times. iPod iPod mini Stereo Connector Fig.
- Page 6 Operating Instructions STEP 2 - TuneCommand Remote Setup 1. Turn your Remote with the buttons facing Fig. 2 down. Press the release button to open the battery tray, and gently pull it out of the housing until it stops (Fig. 2). Please do not force the battery tray completely out of the housing.
- Page 7 Operating Instructions STEP 2 - TuneCommand Remote Setup Use the stereo connector on top of the TuneCommand Receiver to connect your iPod to your stereo system. As an alternative, you can connect to your stereo system via the iPod device’s docking cradle and its built-in line-out port.
- Page 8 Operating Instructions ����� ������������������� LED Chart Every time you push a button on the ����� ������������������� Green Received the signal Remote, the green lights on the Remote and the Receiver blink, indicating that the signal has been received correctly. If the Remote and the Receiver are too far apart to communicate, the light on ��������������������������������...
- Page 9 Operating Instructions Using the Multi-Clip � Do not slide on � SNAP � � Snap the clip on the Transmitter How to clip on the belt � � Adhesive backing attaches to smooth surface � � How to snap on the clip when using the lanyard (the clip is to be used upside down in this case) �...
-
Page 10: Troubleshooting
Troubleshooting Receiver is not powering on when plugged into the iPod. Remove the Receiver and reinstall into the top of your iPod. Ensure your iPod is charged or connected to power, and turned on. Remote handset is not powering on. Ensure that the Remote battery is inserted correctly, with the (+) facing up, that the battery tray is fully pushed in, and the release button is snapped back into position. -
Page 11: Specifications
Specifications Operating Range: Up to 120 ft. / 37 m. Transmission Method: Radio frequency Frequency: 2.44GHz Remote Battery: CR2032 3V Remote Dimensions: 2.75” x 1.25” x 0.5” (not including belt clip; 0.75” max depth including belt clip) Remote Weight (including battery): 0.8oz. (33.9g) Receiver Dimensions: 1.57”... - Page 12 Belkin Corporation warrants this product against defects in materials and workmanship for three years. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product.
- Page 13 FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 14 Belkin Tech Support Europe: 00 800 223 55 460 © 2005 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
