Section 3: Configuration
You may configure up to 3 video profiles with different settings for your camera. Hence, you may set up different profiles for your computer and
mobile display. In addition, you may also configure the two-way audio settings for your camera. After making any changes, click the Save Settings
button to save your changes.
Aspect ratio:
Mode:
Frame size / View window area:
Maximum frame rate:
D-Link DCS-6513 User Manual

Audio and Video

Set the aspect ratio of the video to 4:3 standard or 16:9
widescreen.
Set the video codec to be used to JPEG, MPEG-4, or
H.264.
Frame size determines the total capture resolution, and
View window area determines the Live Video viewing
window size. If the Frame size is larger than the Live
Video size, you can use the ePTZ controls to look around.
16:9 1920 x 1080, 1280 x 720, 800 x 450,
640 x 360, 480 x 270, 320 x 176, 176 x 144
up to 30 fps
4:3 1600 x 1200, 1024 x 768, 800 x 600,
640 x 480, 320 x 240, 176 x 144 up to 30 fps
2048 x 1536 at 15 fps
Note: If your View window area is the same as your Frame
size, you will not be able to use the ePTZ function.
A higher frame rate provides smoother motion for
videos, but requires more bandwidth. Lower frame rates
will result in stuttering motion, however will require less
bandwidth.
