If printing is blurry even when the ink roller is in the proper position, replace the roller.
Ink roller: Type EA-741R
WARNING
APPLYING INK TO WORN INK ROLLER OR USE OF UNAPPROVED INK ROLLER
MAY CAUSE SERIOUS DAMAGE TO PRINTER.

1. Set the power switch to the OFF.

2. Remove the printer cover by sliding it. (Fig. 1)
3. Move the knob of the ink roller slightly towards you and then lift it up (in the direction
of the arrow). Take care not to catch the ink roller under the case. (Fig. 2)
4. Install the new ink roller and push the knob of the ink roller. Make sure that the ink
roller is securely in place. (Fig. 3)
5. Put back the printer cover.
Note: When you clean the printer cover, remove the printer cover by sliding it. (Fig. 1)
Then clean the printer cover by using a soft, dry cloth. Do not use solvents or a
wet cloth.
Fig. 1

Cleaning the printing mechanism

If the print becomes dull after long time usage, clean the printing wheel according
to the following procedures:
1) Install the paper roll and feed it until it comes out of the front of the print mechanism.
2) Remove the printer cover and the ink roller.
3) Put a small brush (like a tooth brush) lightly to the printing wheel and clean it by
pressing .
4) Put back the ink roller and the printer cover.

INK ROLLER REPLACEMENT

Fig. 2
Knob of the
ink roller
– 7 –
Fig. 3
