Installation Instructions
for Stacked Dryers
Inside.......................................
Dimensions........................................................................
Before You Start................................................................
Installing the Dryer............................................................
Installer Checklist................................................. Back Cover
Date Purchased _____________________
Model Number _____________________
Serial Number ______________________
Keep these instructions for future reference.
(If this machine changes ownership, this manual must accompany machine.)
3
4
5
www.comlaundry.com
Part No. 512042R4
December 2008
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems 512042R4
Summary of Contents for Alliance Laundry Systems 512042R4
-
Page 1: Installation Instructions
Before You Start..............Installing the Dryer............Installer Checklist..........Back Cover Date Purchased _____________________ Model Number _____________________ Serial Number ______________________ Keep these instructions for future reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 512042R4 December 2008 www.comlaundry.com... - Page 2 All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
-
Page 3: Dimensions
(39.2 cm) (11.4 cm) 26.9 in. 0.4 in. (68.3 cm) DRY2285N (1.1 cm) GAS DRYERS DRY2285N *With leveling legs turned into base. 3/8 in. N.P.T. Gas Connection © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042... -
Page 4: Before You Start
Wrench Screwdrivers Level Teflon Tape Duct Tape Figure 1 WARNING Any disassembly requiring the use of tools must be performed by a suitably qualified service person. W299 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042... -
Page 5: Installing The Dryer
Exhaust duct clearance to combustible material 2 in. (5.1 cm) **NOTE: For new installations, locate top of wall vent 42 inches (106.7 cm) above floor to make venting easier to connect. Figure 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042... - Page 6 (mobile) home installation. Follow To reduce the risk of fire, DO NOT use the instructions supplied with the kit. plastic or thin foil ducting to exhaust the dryer. W354 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 7 • Ductwork that runs through unheated areas must be insulated to help reduce condensation and lint build-up on pipe walls. • Each exhaust duct must be vented separately. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
-
Page 8: Exhaust Direction
NOTE: The maximum length of a 4 inch (10.2 cm) diameter flexible metal duct must not exceed 7.87 feet (2.4 m), as required to meet UL2158, clause 7.3.2A. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042... - Page 9 Dryer is stainless steel connector. equipped at the factory for Natural Gas with a 3/8 inch NPT gas connection. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 10 ) service must be supplied at 10 ± 1.5 inch Service without converting the gas valve. Install water column pressure. L.P. Gas Conversion Kit 649P3, available at extra cost. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 11 The power cord connection between wall receptacle and dryer terminal block IS NOT supplied with dryer. Type of power cord and gauge of wire must conform to local codes. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 12 3. Use a strain relief and insert end of power cord through power supply hole. 2. Remove access cover from rear of dryer. D696I D695I Figure 8 Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 13 8. Reinstall access cover and screw. D695I Figure 11 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 14 D698I center grounding pin of the plug and the green D698I screw on the back of the cabinet. Figure 14 10. Reinstall access cover and screw. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 15 8. Using screwdriver, remove two door plugs, and reinstall on opposite side of door opening. DRY1916N DRY1916N 4. Rotate door panel 180 degrees as shown. DRY2052N DRY2052N D273P © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 16 • Do not use an extension cord. • Do not operate both a washer and gas dryer on the same circuit. Use separetely fused 15 amp circuits. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 17 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
- Page 18 D700I Shut-Off Valve Handle Open Position Closed Position Air Shutter Lockscrew Air Shutter 1/8 in. (3.1 mm) Pipe Plug (For checking manifold pressure) Figure 19 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 512042...
-
Page 20: Installer Checklist
Installer Checklist Fast Track for Installing the Dryer (Refer to the manual for more detailed information) • Position and • Wipe Out Inside Level the Dryer. of Dryer. LEVEL D255I D255I D256I CHECK D259I CHECK DRY2058N • Connect Dryer • Plug In the Dryer. Exhaust System.
