General Cleaning
To Remove and Replace Oven Door
To Remove Oven Door:
1. Pull the door open.
2. While supporting the door with one hand, remove the 2 screws securing the top hinge to the door.
3. Remove the top hinge, then lift up the door to clear the lower hinge pin and remove the door.
To Replace Oven Door:
1. Insert the door into the lower hinge.
2. Replace the top hinge, and secure it to the door with the 2 screws.
To Remove and Replace Oven Door
1. Open the door to the fully opened position.
2. Pull up the lock located on each hinge support and engage it in the hook of the hinge lever. You may have to apply a little
downward pressure on the door to pull the locks fully over the hooks.
3. Grasp the door by the sides, pull the bottom of the door up and toward you to disengage the hinge supports.
Keep pulling the bottom of the door toward you while rotating the top of the door toward the appliance to completely disengage
the hinge levers.
4. Proceed in reverse to re-install the door. Make sure the hinge supports are fully engaged before unlocking the hinge levers.
Note: It should not be necessary to remove a side swing door for cleaning. If door needs to be removed, refer to the installation
instructions.
Lock in normal
position

Changing Oven Light

On some models an interior oven light will turn automatically when the oven door is opened. The oven light may be
turned on when the door is closed by using the oven light switch located on the control panel.
On some models, the lamp is covered with a glass shield held in place by a wire holder.
THIS GLASS SHIELD MUST BE IN PLACE WHENEVER THE OVEN IS IN USE.
To replace the light bulb:
CAUTION: BE SURE THE OVEN IS COOL.
1. Turn the power off at the main source.
2. Wear a leather-faced glove for protection against possible broken glass.
3. Replace bulb with 40 watts appliance bulb only.
4. For models with glass shield, press holder on one side to release glass shield, change bulb
and be sure to replace the glass shield.

Adjusting Oven Temperature

For instructions on how to adjust the oven temperature refer to the timer section or the electronic oven control guide.
(continued)
(side swing door models, some models)
(down swing door models, some models)
Lock engaged
for door removal
11
HINGE SLOT
Door removed from
the range
