1.2 Name of each section (terminal)

TLF001Z
○ RUN
○
SCAN
○ AUX
○ POWER
1 SL1
2 SL2
3 SG
4 SHD
1 PGA1
2 PGA2
3 PGB1
4 PGB2
5 PGZ1
6 PGZ2
7 PGVC
8 PGCC
LED for status display
SL1 Transmitting and receiving data (positive)
SL2 Transmitting and receiving data (negative)
TB1
SG Signal ground
SHD Terminal for shield (no connection inside)
PGA1 Phase A, PG feedback anode side
PGA2 Phase A, PG feedback cathode side
PGB1 Phase B, PG feedback anode side
PGB2 Phase B, PG feedback cathode side
TB2
PGZ1 Phase Z, PG feedback anode side
PGZ2 Phase Z, PG feedback cathode side
PGVC 12V power supply
PGCC Common terminal for control signal *1
*1: Connect this PGCC terminal to the CC terminal on the
control board of the inverter.
6
E6580772
