Smart-DTA™
ISDN VoIP Telephone Adapter
Quick Start Guide
Important
environment. It is not intended nor approved for use in an industrial environment
Caution
cation network.
Attention
télécommunication public le RNIS.
Vorsicht
Telekommunikationsnetz genehmigt.
Precaución
telecomunicaciones pública ISDN.
Attenzione
telecomunicazione pubblica ISDN.
Document Number: 13228U7-002 Rev. B
Part Number: 07MSDTA1-QS
Revised: October 26, 2007
This is a Class B device and is intended for use in a light industrial or residential
—
—This device is not intended nor approved for connection to the public ISDN telecommuni-
—Ce dispositif n'est pas prévu ni approuvé pour le raccordement au réseau de
—Dieses Gerät ist nicht für Anschaltung an das öffentlich ISDN
—Este dispositivo no está previsto ni se ha aprobado para la conexión a la red de
—Questo dispositivo non è inteso né non approvato per collegamento alla rete di
.
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Patton electronics Smart-DTA
Summary of Contents for Patton electronics Smart-DTA
-
Page 1: Quick Start Guide
Smart-DTA™ ISDN VoIP Telephone Adapter Quick Start Guide Important This is a Class B device and is intended for use in a light industrial or residential — environment. It is not intended nor approved for use in an industrial environment Caution —This device is not intended nor approved for connection to the public ISDN telecommuni-... - Page 2 CAUTION Connect the Smart-DTA to a power source using the included power supply and cable. When the Power LED stops blinking and remains lit, the Smart-DTA is ready to configure. Smart-DTA Quick Start Guide...
- Page 3 2.0 Connect the Smart-DTA to your local network You must connect the Smart-DTA to an IP network that provides a DHCP server. Using the included black Ethernet cable, connect the Smart-DTA RJ-45 Ethernet WAN port, labeled ETH (see 1), to an Ethernet hub or switch figure...
- Page 4 3.0 Connect the Smart-DTA to an ISDN phone Using a straight-though cable, terminated with RJ-45 connectors, connect the BRI port of your Smart-DTA to the S/T port of your ISDN phone, as shown below: ISDN Phone RJ-45, male RJ-45, male Note: Other pins are not used.
-
Page 5: Start The Smartnode Discovery Tool
• Make sure any firewall programs on your PC are disabled 5.0 Access the Web Browser (GUI) Interface In the SmartNode Discovery Tool window, select the line that displays the IP address of your Smart-DTA. SmartNode Discovery Tool window Figure 2. - Page 6 Right-click the selected line, and select Webbrowser. The Login window will display. Login window Figure 3. Enter the username administrator. Do not enter a password. Instead simply click OK. Your web browser will display the Smart-DTA home page. Smart-DTA home page Figure 4. Smart-DTA Quick Start Guide...
-
Page 7: Configuring Your Smart-Dta
Once you have logged in you can use the browser-based graphical user interface (GUI) to configure and manage your S-DTA. The Smart-DTA home page displays three Immediate Actions buttons that allow you to store the cur- rent configuration state, reload the device, and restore to factory defaults. The home page also displays certain basic system information. -
Page 8: Customer And Technical Support
B.0 Appendix—Factory default IP addresses Factory default IP addresses and netmask configuration. IP Address Network mask DHCP Client WAN interface Ethernet 0 (0/0) 192.168.1.1 255.255.255.0 LAN interface Ethernet 1 (0/1) 192.168.1.10-192.168.1.99 255.255.255.0 DHCP server address range (LAN) Smart-DTA Quick Start Guide... -
Page 9: Compliance Information
The Smart-DTA router have been tested and found to comply with the limits for a Class B computing device in accordance with specifications in Subpart B of Part 15 of FCC rules, which are designed to provide rea- sonable protection from such interference in a commercial installation. - Page 10 NOTES ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Smart-DTA Quick Start Guide...
- Page 11 NOTES ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Smart-DTA Quick Start Guide...
-
Page 12: Copyright Statement
The information in this document is subject to change without notice. Patton Electronics assumes no liability for errors that may appear in this document. Trademarks statement The term Smart-DTA is a trademark of Patton Electronics Company. All other trademarks presented in this docu- ment are the property of their respective owners. Warranty For warranty information, refer to the Smart-DTA Getting Started Guide located on the CD-ROM that came with your IAD or available online at www.patton.com.
