Patton electronics EnviroNET 2100 Series User Manual
Hide thumbs
Also See for EnviroNET 2100 Series:
- User manual (43 pages) ,
- Quick start manual (13 pages)
Table of Contents
Advertisement
Quick Links
For Quick
Start Installation
EnviroNET™ 2100 Series
Ethernet Extenders
User Manual
Important
residential environment.
Important
premise equipment.
–This is a Class A device and is intended for use in an industrial environment. It is not intended nor approved for use in a
–This device is NOT intended nor approved for connection to the PSTN. It is intended only for connection to customer
Sales Office:
+1 (301) 975-1000
Technical Support:
+1 (301) 975-1007
E-mail:
support@patton.com
WWW:
www.patton.com
Document Number: 06401U2-001, Rev. A
Part Number: 07MEN2100-UM
Revised: October 22, 2007
Advertisement
Table of Contents
Related Manuals for Patton electronics EnviroNET 2100 Series
Summary of Contents for Patton electronics EnviroNET 2100 Series
-
Page 1: User Manual
For Quick Start Installation EnviroNET™ 2100 Series Ethernet Extenders User Manual Important –This is a Class A device and is intended for use in an industrial environment. It is not intended nor approved for use in a residential environment. Important –This device is NOT intended nor approved for connection to the PSTN. - Page 2 Patton Electronics Company, Inc. 7622 Rickenbacker Drive Gaithersburg, MD 20879 USA Tel: +1 (301) 975-1000 Fax: +1 (301) 869-9293 Support: +1 (301) 975-1007 Web: www.patton.com E-mail: support@patton.com Trademark Statement Trademark names and copyrights are the registered trademarks or copyright names of the respective owners and owned by them.
-
Page 3: Table Of Contents
Contents Contents ................................. 3 About this guide ............................. 5 Audience................................. 5 Structure................................. 5 Precautions ................................6 Safety when working with electricity .........................7 General Information............................8 Overview .................................9 Features ...................................9 Types of EnviroNET models ..........................10 Interface Options..............................11 Installing the EnviroNET ..........................12 Before you begin..............................13 What you will need... - Page 4 Contents EnviroNet User Manual Configuring DIP Switch S1 ..........................28 Switch 1: Ethernet Auto Sense ........................29 Switches 2, 3, and 4: Data Rate .........................29 Switches 5, 6, 7, and 8: Reserved .......................30 Other Models ................................30 Operating the EnviroNET..........................31 Powering up the EnviroNET..........................32 LEDs (ET and EC models only)..........................32...
-
Page 5: About This Guide
About this guide This guide describes the EnviroNET Ethernet Extenders Series hardware, installation and basic configuration. Audience This guide is intended for the following users: • Operators • Installers • Maintenance technicians Structure This guide contains the following chapters and appendices: •... -
Page 6: Precautions
EnviroNET User Manual About this guide Precautions Notes, cautions, and warnings, which have the following meanings, are used throughout this guide to help you become aware of potential problems. Warnings are intended to prevent safety hazards that could result in per- sonal injury. -
Page 7: Safety When Working With Electricity
EnviroNET User Manual About this guide Safety when working with electricity This device is to be installed only by qualified service person- • nel. It contains no user serviceable parts, and shall be returned to Patton Electronics for repairs, or repaired by qual- ified service personnel. -
Page 8: General Information
Chapter 1 General Information Chapter contents Overview .................................9 Features ...................................9 Types of EnviroNET models ..........................10 Interface Options..............................11... -
Page 9: Overview
EnviroNET User Manual 1 • General Information Overview EnviroNET™ Ethernet Extenders provide transparent extension of your 10/100 Ethernet LANs at distances up to 8 km over a single twisted pair or line rates up to 50 Mbps! EnviroNET Ethernet Extenders operate at line rates from 192 kbps to 50 Mbps depending on the model selected. -
Page 10: Types Of Environet Models
EnviroNET User Manual 1 • General Information Types of EnviroNET models The EnviroNET Ethernet Extender comes in three different model configurations: Extended, Hardened, and Controlled. • Extended (ET) Temperature from -40ºC to 85ºC (-40ºF to 185ºF) Has a heater and a fan Has 2 LEDs, Power and Temperature Control Indicator •... -
Page 11: Interface Options
EnviroNET User Manual 1 • General Information Interface Options The EnviroNET Ethernet Extender can be made with different models from the Patton CopperLink Ethernet Extender product line. The EnviroNET Ethernet Extender models and features are listed in table Table 1. EnviroNET Ethernet Extender Models and Features Model Temperature Case Rating... -
Page 12: Installing The Environet
Chapter 2 Installing the EnviroNET Chapter contents Before you begin..............................13 What you will need ............................13 Opening the case .............................13 About the Hardware ..............................14 PC Board ................................15 AC/DC Power Supply ............................16 Interface Board ...............................16 Wiring the power ..............................17 Running the power cable through the gland ....................17 Connecting the power cable wires to the EnviroNET ..................18... -
Page 13: Before You Begin
EnviroNET User Manual 2 • Installing the EnviroNET Before you begin... Before you can use the EnviroNET, you must first wire the power cable, wire the terminal block, and configure the unit. Note You should complete the wiring and configuration of the EnviroNET before you mount the unit. -
Page 14: About The Hardware
EnviroNET User Manual 2 • Installing the EnviroNET Note If you are unsure about the location or nature of the EnviroNET components, refer to the following section, “About the Hardware” page 14, before you begin connecting cables and wiring the Enviro- NET. -
Page 15: Pc Board
EnviroNET User Manual 2 • Installing the EnviroNET Console port MDIX Switch Line port Terminal block Power jack LEDs wiring diagram Power supply Ethernet port (ET/EC only POWER ONE BLP-30 AC IN POWER 100-240V DC OUT 0.15A 12V/0.42A BLOCK 50/60Hz PWB-5002 Internal Heater... -
Page 16: Ac/Dc Power Supply
EnviroNET User Manual 2 • Installing the EnviroNET AC/DC Power Supply The AC/DC power supply is installed internally by the factory. However, you will need to wire the power cable externally for the EnviroNET to have power. (See “Wiring the power” on page 17). -
Page 17: Wiring The Power
EnviroNET User Manual 2 • Installing the EnviroNET Wiring the power Inside the EnviroNET, the power cable is wired to the power supply, but it is not wired externally because dif- ferent customers require different lengths of power cable for their specific EnviroNET environments. You will need to provide your desired length of power cable for the unit. -
Page 18: Connecting The Power Cable Wires To The Environet
EnviroNET User Manual 2 • Installing the EnviroNET Connecting the power cable wires to the EnviroNET To connect the power cable wires to the EnviroNET: 1. Run the power cable wires from outside of the EnviroNET through the unscrewed gland (on the far left) to the inside of the unit. -
Page 19: Wiring The Terminal Block
EnviroNET User Manual 2 • Installing the EnviroNET Wiring the terminal block Inside the EnviroNET, the terminal block is wired to the PC board, but it is not wired externally because dif- ferent customers require different lengths of wire for their specific EnviroNET environments. You will need to provide your desired length of CAT5 (twisted pair) wires for the unit. -
Page 20: Connecting The Twisted Pair Wires To The Environet
EnviroNET User Manual 2 • Installing the EnviroNET Connecting the twisted pair wires to the EnviroNET To connect the twisted pair wires to the EnviroNET: 1. Run the twisted pair wires from outside of the EnviroNET through the unscrewed glands (on the right) to the inside of the unit. -
Page 21: Configuring The Environet
EnviroNET User Manual 2 • Installing the EnviroNET Configuring the EnviroNET You should configure the EnviroNET before you mount it. For information on how to configure the EnviroNET, see Chapter 3, “Configuring the EnviroNET” page 22. Mounting the EnviroNET The EnviroNET can be mounted in two ways: wall mount and pole mount. Wall mount The wall mount is the typical way that an EnviroNET can be mounted. -
Page 22: Configuring The Environet
Chapter 3 Configuring the EnviroNET Chapter contents Configuring the EnviroNET ..........................23 EnviroNET Model 2172 ............................23 Configuring DIP Switch S2 ..........................24 Switch 1: Symmetric/Asymmetric Operation ....................25 Switches 2 and 3: Data Rate ........................25 Switches 4, 5 and 6: Ethernet Configuration .....................25 Switch 7: Ethernet Shutdown ........................26 Switch 8: Remote Configuration... -
Page 23: Configuring The Environet
EnviroNET User Manual 3 • Configuring the EnviroNET Configuring the EnviroNET You can configure the EnviroNET via the dip switches on the PC board (except for the 2156 and 2157 mod- els). The following CopperLink models are available with the EnviroNET Ethernet Extender series: •... -
Page 24: Configuring Dip Switch S2
EnviroNET User Manual 3 • Configuring the EnviroNET Configuring DIP Switch S2 DIP switch S2 is where you configure the line rate, symmetric or asymmetric, Ethernet, and Ethernet Shut- down. Table 3 summarizes the default positions of DIP switches S2-1 through S2-8. Detailed descriptions of each switch follow the table. -
Page 25: Switch 1: Symmetric/Asymmetric Operation
EnviroNET User Manual 3 • Configuring the EnviroNET Switch 1: Symmetric/Asymmetric Operation To configure the unit for symmetric or asymmetric operation, push the first toggle switch up or down. Refer to table 4 for settings. Table 4. Symmetric/Asymmetric Operation S2-1 Setting Symmetric Operation Asymmetric Operation... -
Page 26: Switch 7: Ethernet Shutdown
EnviroNET User Manual 3 • Configuring the EnviroNET Switch 7: Ethernet Shutdown To enable or disable Ethernet Shutdown, push toggle switch seven (7) up or down. Refer to table 8 for settings Table 8. Ethernet Shutdown S2-7 Description Ethernet Shutdown Enabled Ethernet Shutdown Disabled Switch 8: Remote Configuration To enable or disable Remote Configuration, push toggle switch eight (8) up or down. -
Page 27: Environet Model 2168
EnviroNET User Manual 3 • Configuring the EnviroNET EnviroNET Model 2168 The EnviroNET Model 2168 has eight DIP switches for configuring the EnviroNET for a wide variety of applications. This section describes switch locations and explains the different configurations. Figure 11 shows the orientation of the DIP switches in the On and Off positions. -
Page 28: Configuring Dip Switch S1
EnviroNET User Manual 3 • Configuring the EnviroNET Configuring DIP Switch S1 DIP switch S1 is where you configure the CopperLink line rate, symmetric or asymmetric, Ethernet full auto negotiation capability (100Base-T full or half duplex, 10Base-T full or half duplex) or limited auto sense (only 100Base-T half duplex, 10Base-T full or half duplex) Table 10. -
Page 29: Switch 1: Ethernet Auto Sense
EnviroNET User Manual 3 • Configuring the EnviroNET Switch 1: Ethernet Auto Sense To configure the unit for full auto sense capability or limited auto sense capability, push the first toggle switch up or down. Full Auto sense capability consists of standard Ethernet Auto sensing (100BaseT full duplex, 100BaseT half duplex, 10BaseT full duplex, and 10BaseT half duplex). -
Page 30: Switches 5, 6, 7, And 8: Reserved
EnviroNET User Manual 3 • Configuring the EnviroNET Switches 5, 6, 7, and 8: Reserved Switches 5, 6, 7, and 8 are reserved and should be in the ‘Off ’ position. Table 14. Reserved for future use S1-5 S1-6 S1-7 S1-8 Reserved Reserved (Factory Default) -
Page 31: Operating The Environet
Chapter 4 Operating the EnviroNET Chapter contents Powering up the EnviroNET..........................32 LEDs (ET and EC models only)..........................32 ET models ..............................32 EC models ..............................32 About Thermal Operation (ET Models only) ......................33 Operating the EnviroNET.............................33... -
Page 32: Powering Up The Environet
EnviroNET User Manual 4 • Operating the EnviroNET Powering up the EnviroNET The EnviroNET is designed to be powered on automatically. There is no power switch. The green power LED will light when the power is on (ET and EC models only). To power the EnviroNET: 1. -
Page 33: About Thermal Operation (Et Models Only)
EnviroNET User Manual 4 • Operating the EnviroNET About Thermal Operation (ET Models only) The ET model is the only EnviroNET model that includes a heater. The ET unit will not turn on at -40ºC (- 40ºF). The heater controller monitors the temperature until it is warm enough to turn on the device. The device inside cannot be turned on below 0ºC (32ºF). -
Page 34: Contacting Patton For Assistance
Chapter 5 Contacting Patton for assistance Chapter contents Introduction ................................35 Contact information..............................35 Patton support headquarters in the USA ......................35 Alternate Patton support for Europe, Middle East, and Africa (EMEA) ............35 Warranty Service and Returned Merchandise Authorizations (RMAs)..............35 Warranty coverage ............................35 Out-of-warranty service ..........................36 Returns for credit... -
Page 35: Introduction
EnviroNET User Manual 5 • Contacting Patton for assistance Introduction This chapter contains the following information: • “Contact information”—describes how to contact Patton technical support for assistance. • “Warranty Service and Returned Merchandise Authorizations (RMAs)”—contains information about the warranty and obtaining a return merchandise authorization (RMA). Contact information Patton Electronics offers a wide array of free technical services. -
Page 36: Out-Of-Warranty Service
EnviroNET User Manual 5 • Contacting Patton for assistance Out-of-warranty service Patton services what we sell, no matter how you acquired it, including malfunctioning products that are no longer under warranty. Our products have a flat fee for repairs. Units damaged by lightning or other catastro- phes may require replacement. - Page 37 Appendix A Compliance Chapter contents Compliance ................................38 EMC Compliance: ............................38 Safety Compliance: ............................38 PSTN Regulatory Compliance: ........................38 Radio and TV Interference (FCC Part 15) ......................38 CE Declaration of Conformity ..........................38 Authorized European Representative ........................39...
-
Page 38: A Compliance
EnviroNET User Manual A • Compliance Compliance EMC Compliance: • FCC Part 15, Class A • EN55022, Class A • EN61000-6-2 Safety Compliance: • UL60950-1/CSA C22.2 No. 60950-1 • IEC/EN 60950-1 • AS/NZS 60950-1 PSTN Regulatory Compliance: Note This device is NOT intended nor approved for connection to the PSTN. It is intended only for direct connection to customer premise equipment. -
Page 39: Authorized European Representative
EnviroNET User Manual A • Compliance Authorized European Representative D R M Green European Compliance Services Limited. Oakdene House, Oak Road Watchfield, Swindon, Wilts SN6 8TD, UK Authorized European Representative... - Page 40 Appendix B Specifications Chapter contents EnviroNET Model 2156 ............................41 EnviroNET Model 2157 ............................42 EnviroNET Model 2168 ............................42 EnviroNET Model 2172 ............................43...
-
Page 41: B Specifications
EnviroNET User Manual B • Specifications EnviroNET Model 2156 Table 15. EnviroNET™ Ethernet Extender Model 2156 - Specific Specifications CopperLINK Ethernet Extender - Model 2156 Description 2.3 Mbps Ethernet Extender Data Rate 2304 kbps Diagnostics V52 compliant (511/511E) pattern generator and detector with error injection mode and Remote Loopback control by a single front panel switch Transmission Line Single Twisted Pair of Copper... -
Page 42: Environet Model 2157
EnviroNET User Manual B • Specifications EnviroNET Model 2157 Table 16. EnviroNET™ Ethernet Extender Model 2157 - Specific Specifications CopperLINK Ethernet Extender - Model 2157 Description 4.6 Mbps Ethernet Extender with Auto-Rate Adaptation Line Rate Auto-Rate adaptive from 192 kbps to 4.6 Mbps DTE Rate All 64k steps from 192 to 4608 kbps Transmission Line... -
Page 43: Environet Model 2172
EnviroNET User Manual B • Specifications EnviroNET Model 2172 Table 18. EnviroNET™ Ethernet Extender Model 2172 - -Specific Specifications CopperLINK Ethernet Extender - Model 2172 Description 50 Mbps Ethernet Extender Line Interface RJ-45 (pin 4 = ring; pin 5 = tip) Ethernet Interface 8-position shielded RJ-45.
