Patton electronics 505M-CHC User Manual

Surge protected db-25 to rj-45 modular adapter
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Part# 07M505MCHC-A
Doc# 074281U,
Rev. B
Revised 1/21/08
C E R T I F I E D
An ISO-9001
Certified Company
USER
MANUAL
MODEL 505M-CHC
Surge Protected
DB-25 to RJ-45 Modular
Adapter
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007
http://www.patton.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 505M-CHC and is the answer not in the manual?

Questions and answers

Related Manuals for Patton electronics 505M-CHC

Summary of Contents for Patton electronics 505M-CHC

  • Page 1 USER MANUAL MODEL 505M-CHC Surge Protected DB-25 to RJ-45 Modular Adapter SALES OFFICE Part# 07M505MCHC-A Doc# 074281U, (301) 975-1000 Rev. B TECHNICAL SUPPORT Revised 1/21/08 C E R T I F I E D (301) 975-1007 An ISO-9001 http://www.patton.com Certified Company...

  • Page 2: Radio And Tv Interference

    1.1 RADIO AND TV INTERFERENCE The Model 505M-CHC does not generate or use radio frequency energy. However, when used together with other devices that generate or use radio frequencies, improper installation may interfere with radio and television reception.
  • Page 3 NOTE: Packages received without an RMA number will not be accepted. Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Patton Model 505M-CHC. Technical Service hours: 8AM to 5PM EST, Monday through Friday.

  • Page 4: General Information

    The method of surge protection used in the Model 505M-CHC adds four benefits to your system: 1) High Surge Capacity . The Model 505M-CHC dissipates up to 1500 Watts per wire in 1.0 millisecond. 2) Quick Response. The Model 505M-CHC has a fast response time (1 pS at the component level;...
  • Page 5 Connect one loop to the device chassis (or other chassis ground) and the other loop to the Model 505M-CHC as shown below. Connect to D-Sub Screw Connect to Chassis Ground Figure 1. How to Connect the Patton Model 505M-CHC to Your PC, Modem or Printer...
  • Page 6 APPENDIX A PATTON MODEL 505M-CHC SPECIFICATIONS Connectors: DB-25 male, RJ-45 jack Pins Wired: Pin 2, Transmitted Data; Pin 3, Received Data; Pin 7, Signal Ground. Surge Capacity: 1.5 kW (10 x 1000μSec) in Compliance with IEC 801-5 Level 3, 2kV...
  • Page 8 Dear Valued Customer, Thank you for purchasing Patton Electronics products! We do appreciate your business. I trust that you find this user manual helpful. We manufacture one of the widest selections of data communications products in the world including CSU/DSU's, network termination units, powered and self-powered short range modems, fiber optic modems, interface converters, baluns, electronic data switches, data-line surge protectors, multiplexers, transceivers, hubs, print servers and much more.
