Tips For Owners Of Audiosystems Ews64; Multiple Ews 88 In One System - TerraTec EWS88 MT Manual

Tips for owners of AudioSystems EWS64.

If you own an AudioSystem EWS64 with the digital-board (one of the expansion modules or
DigitalXtension 'R'), you can connect this to the EWS. Run the EWS64 S/PDIF-output to the co-
axial input of the EWS88. We suggest you read the paragraph on digital synchronization via
S/PDIFon page 37 "The ADAT connectors on EWS88 D.".
One more thing, though: The "Control Panel" in this manual refers to the supplied software
package for the AudioSystem EWS88. The good old EWS(64)-Panel will be referred to explicitly
when necessary.

Multiple EWS 88 in one system.

Up to four EWS88 can be installed and run in sync in one PC. This configuration produces 40 in
and outputs, which can all be accessed from your favorite sequencer. Both cards – EWS88 D
and MT – may be combined freely.
Currently (driver version 4.02.16.98) you have access to only 1 SystemSound output when
running multiple EWS 88 – the most recent driver will be activated automatically.
To ensure faultless operation of multiple PCI cards, all PCI cards must be connected to each
®
other using a special connector cable (supplied), or the optional EWS ClockWork. This
connection will guarantee perfect sync of all cards. Please read the chapter entitled "Card
connectors and their applications." starting on page 33.
The EWS88's ControlPanel recognizes individual cards automatically and allows you to control
the settings on every individual EWS 88 . This way, you will never be shown any "useless"
parameters.
8 AudioSystem EWS88
