Summary of Contents for Speco VM8RM2LCD
- Page 1 VM8RM2LCD 8.4” Rack Mount Monitor User’s Manual Speco Technologies 200 New Highway Amityville, NY 11701 800-645-5516 www.specotech.com...
-
Page 2: Warning
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended. -
Page 3: Important Information
Important Information IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4. -
Page 4: Safety Precautions
Safety Precautions Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Table Of Contents
Table of Contents Warning……………………………………………………………………………………………………. 2 Important Information……………………………………………………………………………………. 3 Safety Precautions……………………………………………………………………………………….. 4 Table of Contents………………………………………………………………………………………… 5 Components………………………………………………………….. …………………………………. 5 Feature……………………………………………………………………………………………………. 6 Exploring Your New Monitor…………………………………………………………………………….. 7 Backside Connections…….………………………………………………………………………….…. 8 Selecting a Location for the Monitor…………………………………………………………………… 8 Connecting your Monitor………………………………………………………………………………… 9 Connecting Devices……………………………………………………………………………………… 10 Setup your Monitor……………………………………………………………………..………………... -
Page 6: Feature
Features ■ Professional TFT LCD for surveillance in 8.4” with multiple connections ■ Compatible with SVGA (800X600) ■ Picture-In-Picture feature that allow multi-picture display ■ High brightness level and contrast ratio with super wide viewing angle ■ Built-in 3D comb filter and 3D de-interlace for display picture performance ■... -
Page 7: Exploring Your New Monitor
Exploring Your New Monitor You can operate your monitor by using the buttons on the front panel. The side panels provide the inputs to connect other equipment to your monitor. Front Panel Back Side... -
Page 8: Backside Connections
Backside Connections AUDIO IN (R, L) ① Stereo Audio Signal Input, this input is for VIDEO1 , VIDEO2 , S-VIDEO (Refer to Note below) ② VIDEO 1 IN Composite signal Input for VIDEO 1 VIDEO 1 OUT Video looping output for VIDEO 1 ③... -
Page 9: Setup Your Monitor
Setup your Monitor AUTO: Auto-optimize displaying picture under PC mode. Enter: This “ Auto” Button can be either “Enter” function in OSD Menu) MENU: OSD menu ON / OFF control.(EXIT Item) ADJUST: Increase or decrease the value on OSD menu. Up: Increase value or turn ON / OFF function. -
Page 10: Color Temp
Menu Setup - Picture Brightness: Picture brightness adjustment Min. ~ Max.:0~100 / Default:55 Contrast: Picture Contrast adjustment Min. ~ Max.:0~100 / Default:50 Sharpness: Sets the desired sharpening enhancement to the picture Min. ~ Max.:0~100 / Default:5 Hue: To adjust the color tint value Min. - Page 11 Menu Setup - PIP ack Mount Multi Picture: This function allows the PIP mode to be selected. Source: The function allows the PIP Sub source to be selected. PIP Swap: Enable PIP sources switching.
-
Page 12: Auto Source
Menu Setup - Function Language: English OSD Menu Timer: Select 5 ~ 60 to determine the time menu show on screen. Default: 30 Mute: To disable the audio function. Default: OFF Display Input: Select ON/OFF. Default: ON Auto Source: The monitor will auto detect the video source when power ON. Select ON / OFF. - Page 13 Menu Setup - VGA H-position : Allows adjustment for horizontal position. V-position : Allows adjustment for vertical position. Phase : Is used to adjust best picture quality. It adjusts the sampling phase across one pixel time. When the phase is not adjusted properly, the picture will be unclear.
-
Page 14: Troubleshooting
Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solution. Symptom Solution ● Makes sure the power cord is plugged in, then press POWER button. Monitor will not turn on ●... -
Page 15: Specifications
Specification Model 8.4” LCD Button Control Power / Source / Adjust / Menu / Auto Display Resolution 800 x 600 @ 56/60/72/75 Active Area 170.4(H) x 127.8(V)mm Dot Pitch 0.213 (H)x 0.213(V)mm Display Ratio Brightness (Central) 250cd/m2 (*1) Contrast Ratio 600 :1 Typ. -
Page 16: Dimensions
Dimensions 8.4” rack mount Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 08/26/10.
