Ibanez TB15 Parts List

ITEM NUMBER
3200186 AA
3200002 AA
3200010 AA
3200270 AA
3200271 AA
3200013 AA
3200014 AA
3200015 AA
3200275 AA
3200276 AA
3200277 AA
3200278 AA
3200279 AA
3200280 AA
3200281 AA
3200282 AA
3200283 AA
3200284 AA
3200285 AA
3200286 AA
3200287 AA
3200288 AA
3200289 AA
3200290 AA
3200291 AA
3200292 AA
3200293 AA
3200294 AA
3200295 AA
3200296 AA
3200297 AA
3200298 AA
3200299 AA
3200300 AA
3200301 AA
3200302 AA
3200303 AA
3200304 AA
3200305 AA
3200306 AA
3200307 AA
3200308 AA
3200044 AA
3200310 AA
3200311 AA
3200312 AA
3200313 AA
3200314 AA
3200045 AA
3200316 AA
3200317 AA
3200048 AA
3200319 AA
3200320 AA
3200321 AA
3200322 AA
3200323 AA
3200324 AA
3200325 AA
TB15/15R PARTS LIST
DESCRIPTION
01 POWER IC TDA2040A
01 OP AMP IC NJM 4558D
01 SWITCHING DIODE 1N4148
01 RECTIFIER DIODE 1N4001
01 REVERB UNIT PSR-6
01 PHONE JACK W201M
01 PHONE JACK W201S
01 PUSH SWITCH JPS2251
01 POWER SWITCH GREEN 120V
01 POWER SWITCH GREEN 250V
01 AC INLET HOLDER 0717-1-PQ
01 FUSE 125V F630mA
01 FUSE 250V T315mA
01 POWER TRANSFRMER TB15 AC100/120V
01 POWER TRANSFRMER TB15 AC230/240V
01 VOLUME POT 09HBF25 B103
01 VOLUME POT 09HBF25 B50KC1
01 VOLUME POT 09HBF25 B104
01 VOLUME POT 12HBF25 A100K
01 C.F. RESISTOR 4.7 OHM 1/6W
01 C.F. RESISTOR 68 OHM 1/6W
01 C.F. RESISTOR 100 OHM 1/6W
01 C.F. RESISTOR 1 KOHM 1/6W
01 C.F. RESISTOR 3.3 KOHM 1/6W
01 C.F. RESISTOR 4.7 KOHM 1/6W
01 C.F. RESISTOR 8.2K OHM 1/6W
01 C.F. RESISTOR 10 KOHM 1/6W
01 C.F. RESISTOR 15 KOHM 1/6W
01 C.F. RESISTOR 33 KOHM 1/6W
01 C.F. RESISTOR 100 KOHM 1/6W
01 C.F. RESISTOR 150 KOHM 1/6W
01 C.F. RESISTOR 470 KOHM 1/6W
01 C.F. RESISTOR 1 MOHM 1/6W
01 RESISTOR FUSIBLE 22 OHM 1/2W
01 MO RESISTOR 100OHM 2W J
01 CERAMIC CAP 33 PF 50V
01 CERAMIC CAP 47 PF 50V
01 CERAMIC CAP 200 PF 50V
01 CERAMIC CAP 270 PF 50V
01 CERAMIC CAP 470 PF 50V
01 CERAMIC CAP 560 PF 50V
01 CERAMIC CAP 104 PF 50V
01 LINE CROSS CAP 103PF/400VAC
01 MYLAR CAP 122 50V J
01 MYLAR CAP 272 50V J
01 MYLAR CAP 472 50V J
01 MYLAR CAP 682 50V J
01 MYLAR CAP 123 50V J
01 MYLAR CAP 183 50V J
01 MYLAR CAP 273 50V J
01 MYLAR CAP 563 50V J
01 MYLAR CAP 104 50V J
01 ELECTRO CAP 0.1UF 50V(NP)
01 ELECTRO CAP 0.33UF 50V(NP)
01 ELECTRO CAP 0.47UF 50V(NP)
01 ELECTRO CAP 1UF 50V(NP)
01 ELECTRO CAP 3.3UF 50V(NP)
01 ELECTRO CAP 22UF 25V(NP)
01 ELECTRO CAP 100UF 25V(SMS)
REMARK
U106
U101-105,301
D101-102
D201-204
RB1
J101
J102,103
SW101
AC1
AC100/120V MODEL
AC230/240V MODEL
VR301
VR104-106
VR101,103
VR102
R137
R301
R109
R101,108,111,133,135
R110,120,121
R124,126,129-132,304
R118,119
R103,113,114,115,123,128,302,303,306
R122,305
R136
R104-107,116,117,134,
R125,127
R112
R102
R201,202
R138
C123
C103
C304
C110
C206,207
C108
C204,205,208-219,301,302
C201
C117,132
C115
C101,124
C122,116
C125
C106
C120,121
C127
C129,131,
C114
C128
C104,107,119,
C102,105,113,303,305,306
C109,118,126
C130
C220,221
Q'TY
1
6
2
4
1
1
2
1
1
1
1
1
1
1
1
1
3
2
1
1
1
1
5
3
7
2
9
2
1
7
2
1
1
2
1
1
1
1
1
2
1
16
1
2
1
2
2
1
1
2
1
2
1
1
3
6
3
1
2
