HANNspree DT02-10U1 Quick Start Manual

DT02-10U1 9.6" Liquid Crystal Display TV
This guide is designed as a reference to help you start using your LCD TV quickly. Please refer to the User's Manual for more detailed installation and safety instructions.

Front View

Front View
Channel select
Menu
Power indicator LED

Making Connections

Connecting to Antenna/Cable TV

S
ANT jack
(VHF/UHF
IN jack)
S
Antenna/CATV
coaxial cable

Connecting to a VCR, VCD, DVD Player, or Video Game Console

1. The illustration presented
here shows you how to
connect your TV to a
VCR, VCD, DVD player
or video game console.
S
4-IN-1 A/V jack
S
Video game
B
console
R
W
Y

Connecting the Power Adapter

Power outlet
S
Power cord
S
DC-IN
Power adapter
Copyright 2004, Hannspree California, Inc. All rights reserved.

Quick Start Guide

Speakers
TV
Volume adjust
Remote IR sensor
1. Connect one end of the VHF/UHF
(Antenna) or CATV cable to ANT
Antenna
Jack (VHF/UHF IN Jack) on the back
of the TV.
2. Connect the other end of the
VHF/UHF (Antenna) or CATV cable
to the Antenna or CATV socket.
2. The cables are
VCR
VCD
DVD
B R W Y
S-Video
AV
connector
connectors
1. Connect the power cord to the power
adapter as illustrated.
2. Plug the power adapter connector into
the DC-IN input jack on the rear panel
of the TV.
3. Insert the three-pronged plug at the
other end of the power cord into a
power outlet.
Note : For information on connecting your
TV to a computer , refer to the user's
manual.

Rear View

Rear View
Audio in (Right, RCA x 1)
A/V and Channel Setup

Watching Broadcast or Cable TV

1. After you have made the appropriate power and
source connections, press the power button
to turn on your television.
2. Press the TV button to select TV.
3. Press the MENU button on the
control panel to enter the OSD menu.
4. Press the
5. Press the MENU button.
6. Press the

Selecting A/V Sources

1. Make sure your TV is turned on and a
device such as a DVD player is connected.
color-coded (black,
2. Press the TV button on the control panel to
red, white, yellow).
select different source signals. TV/CA TV
Connect each color-
channel number, AV1 or AV2 appear on the
coded cable to
screen.
the appropriate
connector on your

Auto Channel Setup

device.
1. Press the MENU button to enter the OSD menu.
2. Use the channel buttons on the control panel to select the "TV Setting" menu.
3. Press the MENU button to enter the TV Setting menu.
4. Press channel buttons to select Auto Program.
5. Press the MENU button to enter the Auto Program Setting submenu.
6. Press channel buttons to select ON or OFF and press the MENU button
7. Your television will begin automatically memorizing the available channels.
S
Audio in (Left, RCA x 1)
Video in (RCA x 1)
S
DC-IN AV2 Antenna/Cable TV line in
Headphone line out
(3.5 mm stereo)
button to select the TV setting.
button to select TV/CATV.
Auto Program
TV Setting
A M + -
CH
Auto Program
ON ON OFF
TV
AV1
AV2
.
MAD-001148
