Instruction manual
EN
English, 1
IDCE 8450 B
IDCE 8450 B S
IDCE 8450 B K
!
This symbol reminds you to read this instruction manual.
!
Keep this manual at hand for immediate reference whenever
necessary. Always store this manual close to the tumble dryer and
remember to pass it on to any new owners when selling or tran-
sferring the appliance, so they may familiarise with the warnings
and suggestions herein contained.
!
Read these instructions carefully: the following pages contain
important information on installation and useful suggestions for
operating the appliance.
Contents
Installation, 4
Special programmes
Laundry, 11-12
Troubleshooting, 15
Assistance and Guarantee, 16-17-18
TUMBLE DRYER
EN
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Indesit IDCE 8450 B S
Summary of Contents for Indesit IDCE 8450 B S
-
Page 1: Table Of Contents
Starting and selecting a programme Programmes and options, 8-9-10 Programme chart Special programmes Options IDCE 8450 B Opening the door IDCE 8450 B S Laundry, 11-12 Sorting laundry IDCE 8450 B K Care labels Special garments Drying times Warnings and suggestions, 13... -
Page 2: Important Information
Important information To ensure that the condenser dryer functions Failure to clean the filter after each drying cycle efficiently, the following routine maintenance can undermine drying performance as the machine procedures must be carried out: takes longer to dry and thus consumes more energy. - Page 3 Condenser unit - remove any fluff build-up from the condenser on a monthly basis. Step 1 Open the condenser cover - grip the handle and pull towards you. Step 2 Remove the condenser by turning the 3 catches, then pull the condenser towards you.
-
Page 4: Installation
Installation Where to install the tumble dryer Electrical connections • Install the dryer far from gas Before plugging the appliance into the socket, check the following: ranges, stoves, radiators or • Make sure your hands are dry. hobs, as flames may damage it. •... -
Page 5: Description Of The Tumble Dryer
Description of the tumble dryer Features Opening the door Rating plate Water container Press the door Model & Serial Filter Numbers intake Condenser unit grille (cover open) Condenser cover handle (pull to open) Control panel Options Timed Drying On/Off buttons and Start/Pause button button... -
Page 6: Indicator Lights
ON/OFF/Reset button Pressing the button normally will cause the machine to switch on or off. If the button is pressed for 3 seconds while the dryer is in use, the machine will switch off and the running cycle will reset. Programme selection knob Allows for setting the programme: turn until the indicator points towards the desired programme (see Starting and selecting a programme). -
Page 7: How To Carry Out A Drying Cycle
How to carry out a drying cycle Starting and selecting a programme 1. Plug the dryer into the power supply socket. 2. Select the programme according to the type of laundry (see Laundry). 3. Open the door, ensure that the filter is clean and securely placed and that the water container is empty and correctly slotted (see Maintenance). -
Page 8: Programme Chart
Programmes and options Programme chart Max. Cycle Programme load Compatible options duration (kg) Energy Saver 1 Eco Cotton Alarm – Pre anti-crease – Post anti-crease – Delay start 2 Eco Shirts Alarm – Pre anti-crease – Post anti-crease – Delay start Alarm –... - Page 9 Wool Programme This programme is specific for items that withstand tumble drying and are labelled with the symbol. It is suitable for loads of up to 1 kg (about 3 jerseys). We recommend turning the garments inside out before drying them. This programme lasts about 1:00 (hrs:mins), although it may last longer depending on the size and density of the load and on the spin speed used during the wash cycle.
-
Page 10: Options
Options The options allow for customising the selected programme according to one’s own needs. Timed drying After selecting a programme, press the “Timed drying” button to enter a drying time. Every time this button is pressed, the duration of the selected drying cycle appears on the display. When pressed the first time, the highest allowed value for the selected cycle appears on the display. -
Page 11: Laundry
Laundry Sorting laundry Care labels • Check the symbols on the care labels of the various gar- Always check the care labels, especially when placing ments to verify whether the garments can be safely tumble garments in the tumble dryer for the first time. Below are the dried. -
Page 12: Special Garments
Special garments • Amount of laundry: single items and small loads may take longer to dry. Blankets and bedcovers: acrylic items (Acilian, Courtelle, • Drying: if items are to be ironed, they can be removed Orion, Dralon) must be dried with great care at low heat. from the dryer while still slightly damp. -
Page 13: Warnings And Suggestions
Warnings and suggestions • Do not tumble dry large, excessively bulky items. This appliance was designed and manufactured in com- • Do not tumble dry acrylic fibres at high temperatures. pliance with current international safety standards. The • Complete each programme with the relative cold drying following information is provided for safety reasons and must phase. -
Page 14: Care And Maintenance
Care and maintenance Disconnecting the power supply Emptying the water container after each cycle Disconnect the dryer when not in use or during cleaning Remove the water container and empty it into a sink or other and maintenance operations. suitable drain outlet, then replace it correctly. Always check the water container and empty it before star- ting a new drying cycle. -
Page 15: Troubleshooting
Troubleshooting If you feel that the dryer is not working properly, consult the following troubleshooting suggestions before contacting the Technical Assistance Centre (see Assistance). Problem: Possible causes / Solutions: The dryer does not start. • The plug has not been inserted far enough into the socket to make contact. •... -
Page 16: Spare Parts
Assistance Spare parts Before calling the Technical Assistance Centre: • Follow the troubleshooting guide to check whether pro- This dryer is a complex machine. Attempting to repair it blems can be solved personally (see Troubleshooting). personally or with the aid unqualified personnel may put the •... - Page 17 5 Year Parts Guarantee Indesit also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time. To...
-
Page 18: After Sales Service
After Sales Service No one is better placed to care for your Indesit appliance during the course of its working life than us - the manufacturer. Essential Contact Information Indesit Service We are the largest service team in UK and Ireland offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service. - Page 20 195089480.00 02/2011...
