Grizzly T10035 Instruction Sheet

T10035 Specifications
Maximum Lifting Capacity ....................3,000 lbs.
Lifting Range .......................................3
Weight .......................................................35 lbs.
T10036 Specifications
Maximum Lifting Capacity ....................5,000 lbs.
Lifting Range ..........................................4"–18
Weight .......................................................58 lbs.
Assembly
Attach the upper handle to the lower handle so
that the release button clicks. Insert the handle
into the handle socket. Tighten the knurled thumb
screw.
Operation
To raise the saddle:
Turn the handle clockwise as far as it will turn
and pump the handle up and down. Turning the
handle clockwise will close the release valve.
To lower the saddle:
Slowly turn the jack handle counterclockwise.
If you need help with the Model T10035 or T10036, call
our Technical Support line at: (570) 546-9663.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "–15
1
2
COPYRIGHT © DECEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JM10101 PRINTED IN CHINA
MODEL T10035/T10036
STEEL/ALUMINUM JACKS
INSTRUCTION SHEET
⁄ "
1
To reduce the risk of death, serious personal
2
injury or property damage when using these
jacks:
• DO NOT overload this jack beyond its
rated capacity. Overloading may result
in personal injury or property damage.
⁄ "
1
8
• ALWAYS support the vehicle with
appropriately rated support stands
before working under it.
• DO NOT attempt to move the vehicle
while the jack is in use.
• ONLY use this jack on a hard level
surface capable of sustaining the load
being supported.
• Always make sure that vehicle load
points are centered in the saddle to
maintain proper balance and stability.
• DO NOT use jack if it begins leaking
fluid or if it sinks when placed under
load. These are indications that the jack
needs to be immediately serviced.
• Only use the jack at appropriate areas
of the vehicle that can safely support
the vehicle's weight.
