Replacing The System Board - Dell Inspiron 535S Service Manual
Service manual
Table of Contents
1 screws (8) 2 system board
Compare the system board that you just removed with the replacement system board to ensure that they are identical.
Replacing the System Board
1. Gently align the system board into the chassis and slide it towards the back of the computer.
CAUTION:
Ensure that the port retention springs are not damaged while replacing the sytem board.
Inspiron 535s/537s
1 back of the computer 2 port retention spring
Inspiron 545s/546s
1 back of the computer 2 port retention springs (3)
