Dell Inspiron 535s Service Manual page 29

1. Align and slide the I/O panel into the I/O panel clamp slot.
2. Replace the screw that secures the I/O panel to the chassis.
3. Connect the cables to the system board connectors.
4. Replace the hard drive (see
5. Replace the support bracket (see
6. Replace the front bezel (see
7. Replace the computer cover (see
8. Connect your computer and devices to an electrical outlet, and turn them on.
Back to Contents Page
Replacing a Hard Drive).
Replacing the Support Bracket).
Replacing the Front Bezel).
Replacing the Computer Cover).
