Replacing The Processor - Dell Inspiron 535S Service Manual

1 processor 2 release lever
3 socket
CAUTION: When removing the processor, do not touch any of the pins inside the socket or allow any objects to fall on the pins in the socket.
6. Gently lift the processor to remove it from the socket.
Leave the release lever extended in the release position so that the socket is ready for the new processor.
Replacing the Processor
CAUTION: Ground yourself by touching an unpainted metal surface on the back of the computer.
CAUTION: When replacing the processor, do not touch any of the pins inside the socket or allow any objects to fall on the pins in the socket.
1. Follow the procedures in Before You
2. Unpack the new processor, being careful not to touch the underside of the processor.
CAUTION: You must position the processor correctly in the socket to avoid permanent damage to the processor and the computer when you turn
on the computer.
3. If the release lever on the socket is not fully extended, move it to that position.
Inspiron 535s/537s/545s
Begin.
