16. Relieve
spring t_ )sion on lift lever (see figure 18
and note below) loosening
hex jam nut and un-
screwing
adiustr_lent bolt counter-clockwise
to
obtain 1/4" cleartnce
between
bracket and ad-
justment
bolt.
iiii1_
NOTE
Tractor
lift lever must
be positioned
all
the way back and locked
in position.
BACK VIEW (TRACTOI_)
ADJUSTMENT
BOLT JAM /
r "ATTACHMENT
O
• LIFT SPRING
FIGURE 18
17. Move attachment lift lever all the way forward and
lock in position.
See figure
28 on page 10.
18. Assemble
lift arm link over channel rod and insert
pivot shaft end (from R.H. side of tractor) into hole
in L.H. lift pivot plate.
See figure
19. Secure lift
arm link to channel
rod with
1/8" (large)
hairpin
cotter.
See figure 19
19. Assemble
the frame bracket
(RH) under the right
hand foot rest of the tractor
usin_ -two 3/8 x 3/4"
hex bolts.
Tighten
securely
takiilg
care not to
strip threads.
See figure
19.
R,GHT
HAND SIDE VIEW
FRONT
3/8 X 3/4"
FRAME
BRACKET
REX
/
J//
BOLTS_
/
J
/
/_
S.AFTENO
,IFT
ASSEMBLY_
_
LIFT PIVOT MOUNT
PLATE
ROD
(L.H.)
FIGURE
19
20. Assemble
trunnions that were assembled're
the
lift link rods in step 12, through lift-assembly
arms
and secure
with 7/16" flat washers
and (small)_
hairpin cotters.
Note: Trunnions
must be posi-
tioned
to outside
of lift assembly
arms.
See
figure 20.
RIGHT HAND SIDE VIEW
FRONT
7116" FLAT
LIFT LINK ROD
WASHI
@
HAIRPIN
COTTER
(SMALL)
LIFT ASSEMBLY
LIFT ROD TRUNNION,
ARMS
PLAIN NUT AND LOCK NUT
FIGURE 20
21. Assemble
lift pivot plate over right hand end of lift
assembly
pivot shaft and connect
to outside of
frame
bracket
using two 3/8" x 314" clevis pins
from inside.
Secure with two 3/32" (small) hairpin
cotters.
Secure
ends of pivot shaft to each lift
pivot plate with 1/8" (large) hairpin cotter.
See
figures
20 and 21.
RIGHT
HAND SIDE VIEW
CLEVIS
PINS
FRAME
BRACKET
FRONT
CLEVIS
PINS
LIFT PIVOT
PLATE
LIFT
ASSEMBLY
PIVOT SHAFT
FIGURE
21
22. Assemble
support bracket onto right hand side of
tractor using two 3/8 ° x 1" hex bolts inside and secure,
with,
3/8" lock washers, and 3/8" hex lock nuts on
outside.
See figure 22.
8
