CUSTOMER
RESPONSIBILITES
During the operating season, check all bolts, nuts and
hairpin
cotters to be sure they are secure.
For
improved snow removal
performance, coat the blade
with automotive type paste wax.
LUBRICATION
Oil all pivot points so they will work freely.
SCRAPER
BAR
After extensive use, and wear the scraper bar may be
reversed to utilize the unused top edge.
See figure
35.
STORAGE
When the dozer is not being used, remove all dirt and
rust and touch up with paint.
Apply a light coat of grease or rust preventative to the
blade and oil pivot points.
Store in an area where it is protected from weather.
BLADE _"
BAR
CARRIAGE BOLTS,
LOCK wASHERS
AND NUTS
FIGURE
35
Attachments
That Add to the Usefulness
of Your
Craftsman
Tractor
Seats offers a wide variety of attachments
that for your tractor.
Many of these are listed below with brief
explanations
of how they can help you.
Most of these attachments do not require additional hitches or conversion kits (those that do are indicated) and
are designed for easy attaching and detaching.
You may order these attachments at most Sears retail stores,
catalog sales offices, and through the catalog.
Tire Chains
are heavy duty, closely-spaced
with extra-large
cross links that give smooth ride and outstanding
traction.
Wheel weights
for rear wheels provide needed traction for snow removal or dozing heavy materials.
Weight
(each)
Fits
30 lb.
33 lb.
55 lb.
Lawn Tractor with 8 in. rims
Lawn or Yard Tractors with 10 in. rims
Garden
Tractor
with 12 in. rims
Wheel
weight
mounting
bracket
is available to mount one 55 pound weight on the rear of your tractor frame
for added traction.
13
