- Page 1 CB Series Battery Powered Counting Scales Digital Scales ELECTRONIC SCALE OPERATING MANUAL...
-
Page 2: Specification
Manganese battery - 500hrs , Alkaline battery - 20 Direct PLU keys 0.03 0.66 0.33 0.66 0.001 0.002 E15CB 15,000 0.005/0.01 40~15,000 0.08~30 ~ +40 , 85% MAX.: 0.31W 348(W) × 382.4(L) × 153(H) 4 kg 1,000hrs (Without Back light) 1.33... -
Page 3: Table Of Contents
Error Indication and its Information 1. Introduction Thank you for purchasing our Escali commercially applicable CB SERIES electronic scale. Before using this product, please read the manual carefully in order to fully utilize the features. The protection provided by this equipment may be impaired if this equipment is used in a manner not specified in this manual. -
Page 4: Installation And Details For Caution Use
Keep out water or any liquid-type substance from the scale. Check to see if the scale is placed horizontally before use. If the scale is not in a horizontal position, use the horizontal positioning screw in order to adjust its position. -
Page 5: Name Of Each Part
Use only authorized adapter. Using a different adapter may cause a problem to the scale. When connecting adapter while the battery is in the scale, the battery power will be automatically turned off and adapter power will be charged even though the battery is in the scale. -
Page 6: Keypad And Display Information
Sets up the tare or deletes the tare. [ C ] Delete Key Deletes inputted data. [ Zero ] Zero Key Sets the weight to “0g”. [ ON/OFF ] Power Key Turns the scale on/off. Unit Q'ty £« £½ FUNCTION ZERO TARE ¡Ü... -
Page 7: Function
If the “Shortage Unit Wt.” LCD Is turned on, it means that the unit weight of the scaled product is within the “Unit Weight Short” range Inaccuracy may result when measured in a condition with both “Short Q’ty” and “Short Unit Wt.” LCD turned on. Therefore, scale in a condition when both LCDs are completely turned off. - Page 8 ■ Procedures to save a Preset Key (PLU key) with a Unit weight value Use by saving the unit weight of the frequently scaled product into the preset key. (Save up to 20 PLUs.) Make sure the display is set to “0g” before inputting unit price. 1.
-
Page 9: Procedures To Add Up
■ Procedures to add up the Unit weight Although there are many products to be measured, the quantity of the scaled each objects can be added up disregarding their unit weight. The number of add-ups can be possible up to 99 times and the total add-up value can be possible up to 99,999.999. [ex] Cases when adding up the unit weight of the three different products (ex: unit weight 2g, 1. - Page 10 6. Remove the product B, place the product C WEIGHT ZERO TARE QUANTITY Short Q'ty Short Unit Wt. UNIT WEIGHT TO TAL 7. Push the “+” key Model : CB-15N W ei ghi ng r ange : 40 g ~ 6/15 kg, e = d : 2 g / 5 g ( 0.
-
Page 11: Error Indication And Its Information
■ Procedures to set up time to automatically turn off the power Push the “C” key for 5 seconds while the weight, quantity, unit weight of the scale are zero state and Tare is released as the picture No. 1. -
Page 12: Warranty Regulations
1. Warranty information and term of its validity. The scale's breakdown under normal operating condition is guaranteed for a repair with no charge for 1 year from the date of its purchase. 2. Exception for guaranteed repair. Breakdown caused by following reasons are exceptions for guaranteed repair.
