Shop fox D4033 Instruction Sheet

Model D4033
Shop Fox Drill Press Table
Instruction Sheet
Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz
Damage to your eyes, lungs, and ears could result
from using a drill press without protective gear,
such as safety glasses, a respirator, and hearing
protection.

Specifications

Size ................................. 23
Aluminum Insert T-Slots ........................................2
Wooden T-Slots ..................................................1
Weight ..................................................10
Construction ...........................Melamine-Coated MDF
Color ........................................................ White
Inventory (Refer to Figures 1 & 2)
Table ..............................................................1
Fence .............................................................1
Fence Stop .......................................................1
Knobs .............................................................5
Clamp Assemblies ...............................................2

Installation

1. File down any nicks or burrs in the drill press table,
clean the surface, then wipe a very light coat of
machine oil on the table to prevent rust should any
condensation occur.
2. Place the Model D4033 table onto the drill press
table, align the clamps as shown in Figure 2, then
snug them in place.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
#12963JB
⁄ " W x 11
3
4
COPYRIGHT © JUNE, 2010 BY WOODSTOCK INTERNATIONAL, INC.
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
Fence
Stop
Figure 1. Drill press fitted with Model
⁄ " D x 3" T
7
8
⁄ lbs.
1
2
Qty
Clamp Assembly
Knob
D4033 drill press table.
Figure 2. Installed table.
Printed in China
Fence
Table
