Wind Crest PER Series Install Quick Specs

Island or Peninsula Mounted Hoods – Install Quick Specs
Installation Type & Discharge Direction
Ceiling/Island – vertical discharge

Discharge Size off Hood Top

14" x 4 ¼" rectangular
Discharge Transition – purchased
separately
See "Ventilation" section for options

Standard Features

•
304 Series, 18 gauge stainless steel
•
Halogen lighting (dual 50 watt lamps 36" to
42" widths/four 50 watt lamps 54" width –
with Hi/Lo setting
•
Dishwasher safe, heavy aluminum mesh
filters
•
All Stainless Steel Finish Hoods can be
installed Indoors or Outdoors (see
Installation Instructions)
•
Widths: 36", 42" and 54"

Finishes

•
Stainless Steel (S), White (W), Essence of
Copper (E) and Pewter (P)

Optional Accessories

•
6" or 12" Canopy Extensions in matching
finish (Model(s): 6PEC36S or 12PEC36S
for 36" wide hood in stainless steel finish)
NOTE: Specify desired canopy height,
width & finish when ordering
•
Chrome or Brass Rolled Pot Rails
(Model(s): ACCBRC or ACCBRB) – indoor
use only

Hood Carton Weight:

PER36 = 67 lbs.
PER42 = 78 lbs.
PER54 = 82 lbs.
Copyright 2006 Wind Crest by CNP Industries
Install Quick Specs are for planning purposes only. Please refer to the detailed installation instructions, prior to
making any cutouts.
PER Series Hoods - 30" Depth
Wiring Access
C L
3"
PER Hoods
12"
"PEC" Canopy Extensions (6" or 12"
height) for PER hoods
18"
U L U L
LISTED 7Z66 C
6", 12"
