16 Port 10/100Mbit/s
Ethernet Switch with Optional
Product User Guide
Introduction
This Tyco Electronics auto-negotiating Fast Ethernet workgroup
switch with optional fiber uplink enables clusters of up to 16 users
to have high speed, low latency LAN connections to the corporate
network.
Local management functions such as control of port speed, duplex
mode, port trunking and VLAN membership are supported.
The optional fiber uplink module enables the switch to be
connected using a fiber link to servers, routers and other devices
over distances of up to 2km for multimode or 15km for singlemode.
Package Contents
Unpack the contents and verify them against the items below:-
1. 16 Port Ethernet Switch with fiber uplink option port
2. AC Power cord
3. Four rubber feet
4. Rack mounting kit (2 x brackets and 4 x screws)
5. RS-232 cable
If any item is damaged or missing, please contact your dealer.
Product Part No. 0-1591046-x
Fiber Uplink Port
-
(EMEA) PL0334 Issue 1.2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tyco Electronics 0-1591046-X
Summary of Contents for Tyco Electronics 0-1591046-X
-
Page 1: Package Contents
Ethernet Switch with Optional Fiber Uplink Port Product User Guide Introduction This Tyco Electronics auto-negotiating Fast Ethernet workgroup switch with optional fiber uplink enables clusters of up to 16 users to have high speed, low latency LAN connections to the corporate network. -
Page 2: Technical Support And Service
If you have a faulty unit then please contact us through the web site to arrange for a replacement unit. The faulty unit must be returned to us as part of the replacement agreement. Page 2 Tyco Electronics... -
Page 3: Front Panel
See the documentation on the web site for full information. Rear Panel The rear panel contains the 110/240v AC 50/60Hz power socket. Note that the fusing is external to the switch. Page 3 Tyco Electronics... -
Page 4: Installation
1. Remove the two screws securing the front panel blanking plate located in the right hand side of the panel. 2. Ensure that there is no power on the switch and then carefully fit the plug-in module and secure it using the thumbscrews. Page 4 Tyco Electronics... - Page 5 See the console port instructions on the web site for further details. 7. Note that auto-negotiation can take up to 30 seconds to complete depending on the partner device. Page 5 Tyco Electronics...
-
Page 6: Led Indicators
The port is in full-duplex mode Blinks Collisions in half-duplex mode FDX/COL No device attached or in half duplex Table 1 - LED Status and description See optional fiber module manual or the web site for details. Page 6 Tyco Electronics... -
Page 7: Troubleshooting
If you still have problems and need further advice, please see Technical Support section on page 2 to obtain more information. Page 7 Tyco Electronics... - Page 8 Average Average Plug-In Fiber Ethernet Average Power Sensitivity Module Type Launch Loss Budget Power dB Multimode Converter (SC) Multimode Converter (ST) Multimode Converter (MT-RJ) Singlemode Converter (SC) Table 2 - Optical Specifications Page 8 Tyco Electronics...
-
Page 9: Product Specification
0ºC to 45ºC (32ºF to 113ºF) Temperature Operating 10% to 90% (Non-condensing) Humidity Power Supply Internal 100v to 240v AC, 50/60Hz auto- ranging, externally fused. Power 16 Watts (Max.) Consumption FCC Class A, CE Mark Table 3 - Product Specifications Page 9 Tyco Electronics...
