Fujitsu ServerView Operations Manager V6.12 User Manual page 96

5 User Interface
Enter TFTP step (Create Job Wizard)
Enter TFTP is the fourth step in the wizard. This step is only displayed if the
update runs via TFTP server (for example, in the case of a management
blade or a connection blade).
Figure 18: Enter TFTP step
The table shows a subset of the servers selected on the tab. For the servers
displayed here, update will be done via the TFTP server.
Column
Server
TFTP Address
Temporary Flash
Address
Change TFTP Address
Click this button to change the IP address of the TFTP server for the
selected server.
Change Flash Address
Click this button to change the temporary IP address used for flashing the
management blade (MMBS2 only).
96
Meaning
Name of the server
IP address of the TFTP server
Temporary IP address used for flashing the
management blade (MMBS2 only)
ServerView Update Management
