Summary of Contents for Vizio XVT3D580CM
- Page 1 VIZIO CINEMAWIDE THEATER 3D HDTV ™ ™ WITH VIZIO INTERNET APPS ® MODELS XVT3D500CM XVT3D580CM • QUICK START GUIDE...
-
Page 2: Package Contents
PACKAGE CONTENTS Remote Control with Batteries VIZIO CinemaWide Theater 3D HDTV with Stand Basic Theater 3D Premium Theater 3D Cleaning Cloth Quick Start Guide and Glasses (2 pairs) Glasses (2 pairs) User Manual... -
Page 3: Installing The Base
INSTALLING THE BASE VIDEO DIGITAL AUDIO AUDIO USB 2 USB 1 HDMI [BEST] ETHERNET COMPONENT (BETTER) RGB PC PC AUDIO DTV/TV Place the TV screen-down on a clean, flat surface. To Place the TV on a stable, level surface. prevent scratches or damage to the screen, place the TV on a soft surface, such as carpet, rug, or blanket. -
Page 4: Using The Remote
Go to the previous on-screen menu Display the info window. V.I.A. SHORTCUT BUTTONS V.I.A. Control VIZIO Internet Apps. Open the VIZIO Internet Apps dock. VOLUME UP/DOWN CHANNEL UP/DOWN Increase or decrease loudness of the TV audio. Change the channel. MUTE LAST Turn the sound off or on. - Page 5 SLIDE OUT REMOTE ARROW V.I.A. SHORTCUT BUTTONS Navigate the on-screen menu. Control VIZIO Internet Apps Press and hold while pressing another key to enter a blue character. For example, press ALT and S to enter a # character. SHIFT Press and hold while pressing...
-
Page 6: First Time Setup
FIRST-TIME SETUP Remove the battery cover by pressing gently on the Plug the power cord into an electrical outlet. arrow and sliding away from the remote. Insert the included batteries. Gently slide the battery cover back into place. - Page 7 Ethernet Coaxial Cable Cable If you have an external antenna or a cable connection Turn the TV on by pressing the Power button on the that extends from a wall outlet, connect it to the TV remote. with an RF/Coaxial cable. The Setup App is displayed.
- Page 8 Use the OK and Arrow Up/Down buttons on the Select the name of your wireless network from the list remote to read and accept the Terms of Service and of available networks and press OK. Privacy Policy for Yahoo! TV Widgets. Enter your network key using the on-screen keyboard, When you are finished, highlight Next and press OK.
- Page 9 Enter your First Name, Last Name, Phone Number, Answer the on-screen questions about your TV ZIP Code, and E-mail Address using the on-screen connection using the Arrow and OK buttons on the keyboard. remote. When you have finished the channel scan, highlight Highlight Next and press OK.
-
Page 10: Connecting Your Devices
CONNECTING YOUR DEVICES CONNECTING YOUR DEVICES BACK OF TV Match colored connectors to colored ports. Match colored connectors to colored ports. - Page 11 Choose ONE connection type for each device. Commonly-connected (Cables are not included.) devices: • ANALOG AV CABLE • VIDEO GOOD (480i)* • STEREO AUDIO Cable or Satellite Boxes Match colored connectors • ANALOG to colored ports. COMPONENT CABLE • HD VIDEO BETTER (1080p)* •...
- Page 12 WATCHING CINEMAWIDE Standard 16:9 VIZIO CinemaWide 21:9 Screen Screen Because a 21:9 screen is 30% wider than standard 16:9 screens, your CinemaWide HDTV allows you to view a widescreen movie without the black bars on the top and bottom of the screen.
- Page 13 MULTITASKING Thanks to the CinemaWide screen, you can take advantage of VIZIO Internet Apps while watching your favorite TV or movies. Great ways to use multitasking: • Keep track of league scores while watching your favorite team. • Read the latest headlines while commercials are playing.
- Page 14 GETTING STARTED WITH VIZIO INTERNET APPS Highlighted App V.I.A. Press this button to open the V.I.A. Dock. Be sure your TV is connected to the Internet. The V.I.A Dock is displayed on the bottom of the screen. Use an Ethernet cable or connect wirelessly.
- Page 15 Your V.I.A Dock has many popular apps pre-loaded, but you can add more at any time. To discover and add new apps to the Dock, open the Widget Gallery app. Highlight Categories and press OK. A list of app categories is displayed. When you’ve found an app you want Select a category and browse to add to the Dock, highlight Add...
-
Page 16: How To View 3D
HOW TO VIEW 3D You will need: For the best 3D experience: • 3D Blu-ray™ player* • Try to view the TV straight-on, as shown above. • Blu-ray 3D™ disc* • Do not view the TV at an extreme angle. Some of the • VIZIO Theater 3D Glasses 3D effect will be lost. • 3D-ready HDMI cable connecting the 3D Blu-ray player to your 3D HDTV* • Sit at least 9 feet from the TV. - Page 17 No matter how many guests you’re entertaining, you Blu-ray player, you’ll need to connect it with an HDMI can share your new 3D world with friends and family. cable. VIZIO HDMI cables feature a slim design for easy These 3D glasses are lightweight, comfortable, and installation.
- Page 18 DO YOU HAVE QUESTIONS? LET US HELP! YOUR PRODUCT INCLUDES FREE LIFETIME TECH SUPPORT The VIZIO support team is highly trained and is based in the United States. We can help with: New Product Setup • Connecting Your Devices •...
-
Page 19: Help Topics
HELP TOPICS • The on-screen menu has guided setup. Press MENU, then select HELP > Guided Setup. How do I return to the Select the type of setup you need and press OK. The Setup App will begin. Setup App? • To reset the TV to factory defaults, press MENU >... - Page 20 © 2011 VIZIO INC. ALL RIGHTS RESERVED. 110810ST-NC...
