Page 1: Lcd Monitor
21.6" wide User Manual LCD Monitor English Svenska Deutsch Français Suomi Italiano Dansk Español Polski Nederlands... -
Page 2: Table Of Contents
PRECAUTIONS Information for users applicable in European Union countries Information for users applicable in United States of America Power connection Maintenance Transporting the monitor GETTING STARTED Package contents Monitor installation Identifying parts and controls Working with OSD Group Customizing your Monitor Introduction to Hotkeys The operation of Function menu OSD icon list... - Page 3 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makers for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
-
Page 4: Information For Users Applicable In European Union Countries
PRECAUTIONS Information for users applicable in European Union countries The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources. -
Page 5: Getting Started
GETTING STARTED Package contents Before beginning, ensure that the carton contains the following items: 1. LCD Monitor 2. Monitor Base (the shape of base may vary according to the monitor model) 3. Power Cord (plug may vary according to the electrical standards for your area) 4. -
Page 6: Identifying Parts And Controls
Identifying parts and controls 1.The LED light indicates the state of working. During operation, the LED Light is bright green. When dormant, the LED Light is orange. 2.The power button is used to identify the state of power. You can use the power button to control on &... -
Page 7: Function Keys Operation
Hotkeys Introduction 1.Auto Adjustment When the OSD functions are displayed, press the first button on the left you can automatically optimize the image performance. 2.Volumn Control (Audio matching) When the OSD functions are displayed, press the first button on the right the “AUTO ADJUSTMENT”... - Page 8 OSD Icon List AUTO * Optimize the picture performance automatically. ADJUSTMENT * Activate the built-in color engine to enhance the graphic THEME MODE effects according to the different situations of the display. contents BRIGHTNESS * Adjust the luminance level of the screen. •...
-
Page 9: Osd Icon List
OSD Icon List * Select turn on or turn off DDC/CI function DDC/CI * Factory default: on * 2 seconds after activation of this function, some of the DEMO menus will stimulate feature-grading effects 2 times over. * Show the frequency, resolution, input interface and other INFORMATION operating details about this display. -
Page 10: Troubleshooting
Troubleshooting Symptom 1.No picture 2.LED indicator is not lit. 1.No picture 2.LED indicator is orange 1.Picture shows “ NO SIGNAL INPUT ” 1.Picture shows “ INPUT SIGNAL OUT OF RANGE ” Important Make sure your display setup is under WSXGA 1680*1050,60Hz Check Items 1. -
Page 11: Technical Features And Specifications
Technical Features and Specifications Item 464.94(H) x 290.59(V) mm Display Size Panel 0.27675(H) x 0.27675(V) mm Pixel Pitch Analog D-sub Connector Digital DVI-D(Optional) Tilt Tilt Angle -5°~20° Dimensions About 510 W x 424 H x 202 D mm (W x H x D) Weight About 4.5kg 100~240V, 50Hz/60Hz,1.2A... -
Page 12: Addendum
Addendum Advanced Power Saving Mode 1.Background The traditional monitors have the function of electricity-saving dormancy. But the interval of dormancy is difficult to decide. If the interval is long, the purpose of saving electricity can not be achieved. While the interval is short, your computer and LCD monitor would be dormant often. - Page 13 4.The side effect of the Monitor Life-Extension function (why not preset Advanced Power Saving Mode as default?) According to the request of EPA (U S Environmental Protection Agency) to power management of monitors, the power consumption of the monitor must go down to below 3 watts within 3 seconds after the monitor steps in power saving mode.
-
Page 14: Fcc Compliance
F C C compliance 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
