EMI WLCA Operation Instruction Manual

Emi corp. room air conditioner installation manual & operation instruction

Advertisement

NOMINAL CAPACITIES:
CAH/CAHW: 9,000 - 48,000 Btuh
CAF/CAF4: 8,000 - 36,000 Btuh
GENERAL STATEMENT
IMPORTANT: The information contained in this
manual is critical to the correct operation and main-
tenance of the EMI cassette and should be read by
all persons responsible for the installation, start up
and maintenance of the unit.
SAFETY: The equipment has been designed and manufac-
tured to meet international safety standards but, like any
mechanical/electrical equipment, care must be taken if you
are to obtain the best results.
1. Service and maintenance of this equipment should only
be carried out by skilled personnel.
2. When working with any air conditioning unit ensure that
the electrical disconnect supplying the unit is switched
off prior to servicing or repair work and that there is no
power to any part of the equipment. In the case of a DX
system, both the indoor and outdoor units should be
switched off.
3. Also ensure that there are no other power feeds to the
unit such as fire alarm circuits, BMS circuits, etc.
4. Electrical installation, start up and maintenance work on
this equipment should be undertaken by competent and
trained personnel in accordance with local relevant
standards and codes of practice.
ENVIROMASTER INTERNATIONAL LLC
EMI DUCTLESS SPLIT SYSTEM
CASSETTE EVAPORATOR
INSTALLATION MANUAL/OPERATING INSTRUCTIONS
SPARE PARTS: For ease of identification when ordering
spare parts or contacting Enviromaster International LLC
about your unit, please quote the model number and serial
number. This information can be found on the rating plate
attached to your unit.
PRODUCT DESCRIPTION
The EMI Cassette series is available in nominal capacities
of 9,000 to 48,000 Btuh in DX refrigeration and reverse cycle
heat pump (CAH) or DX with hot water coil (CAHW) ver-
sions; also available are two pipe chilled water (CAF) and
four pipe chilled and hot water versions (CAF4) in 8,000 to
36,000 Btuh capacities; and, depending on the model, elec-
tric heat can also be factory fitted as an option. Designed for
low noise levels, easy installation and maintenance and a
slimline fascia, all ensure minimum obtrusion into the work-
ing environment.
CONTROLS AND COMPONENTS
LOW VOLT TRANSFORMER (Standard): 24 Volt.
ELECTRO-MECHANICAL (Standard): Thermostat options
are cooling only, cooling and one stage auxiliary heat, cool-
ing and one stage mechanical heating (heat pump system)
or cooling and two stage heating (heat pump & second stage
auxiliary heat). An optional thermostat can be obtained through
EMI or your local distributor.
NOTE: Make sure the thermostat is suitable for unit opera-
tion (i.e., cooling only, cooling/electric heat, etc.)
MICROPROCESSOR (Optional): A custom designed mi-
croprocessor is fitted to the cassette to enable room condi-
tions to be maintained at a user defined setpoint. Communi-
cation to the controller is by a hand held infrared transmitter,
which includes a wall mounting bracket as standard.
The microprocessor allows five operating modes. These
modes are - fan only, dry cooling, cooling only, heating only
and heating/cooling auto changeover for maximum versatil-
ity. A temperature setpoint between 58°F - 90°F can also be
selected.
The microprocessor monitors indoor coil temperature and
return air temperature. In heat pump units, a 24VAC signal
from the condensing unit is also monitored to signal the in-
door unit that defrost of the outdoor coil is taking place. This
allows the same micro to control both heat pump and cool-
ing only units. The receiver contains a self diagnostic fea-
ture. When a low indoor coil temperature is detected the
cooling action is stopped. If a sensor fails then an alarm is
1
P/N# 240-4235 Rev. 1.6 [1/05]
EMI@ENVIROMASTER.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLCA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EMI WLCA

  • Page 1 GENERAL STATEMENT IMPORTANT: The information contained in this manual is critical to the correct operation and main- tenance of the EMI cassette and should be read by all persons responsible for the installation, start up and maintenance of the unit.
  • Page 2: Site Installation

    Cassette correctly, it is very important to locate the wall mounted thermostat in the optimum position to en- sure good temperature control. Therefore the installation should be selected with the following points in mind: EMI@ENVIROMASTER.COM A = 12-3/4” min. A = 11-1/2” min. A = 13-1/2” min.
  • Page 3 2. The highest point in the condensate pipework should be as close to the unit as possible. This prevents a large volume of water draining back into the unit when it is switched off. INNER CASE INSULATION FALSE CEILING GUIDE IN POSITION EMI@ENVIROMASTER.COM...
  • Page 4: Electrical Data

    NOTE: Up to two non-adjacent sides can be blanked off. NOTE: On electro-mechanical units, the fascia must be installed with the EMI logo along the same edge of the unit as the electrical panel. On units fitted with microprocessor controls, orient the fascia with the dis- play panel along the same edge of the unit as the electrical panel.
  • Page 5: Start-Up Procedures

    6. The power supply is of the correct voltage and fre- quency. 7. The units are properly grounded in accordance with current electrical codes. MEDIUM LARGE 230V/1PH/60HZ 0.75 1.13 MEDIUM LARGE 230V/1PH/60HZ 13.1 21.7 13.7 22.6 17.1 28.3 MEDIUM LARGE 115V/1PH/60HZ 2.26 EMI@ENVIROMASTER.COM...
  • Page 6 3.3 DISCHARGE 3.4 AMBIENT TEMPERATURE 35. INDOOR AIR TEMPERATURE NOTE: A START UP SHEET FOR EVERY UNIT MUST BE RETURNED TO EMI TO VALIDATE THE WARRANTY. ENVIROMASTER INTERNATIONAL LLC START UP PROCEDURES Once the above pre-start checks have been carried out sat- isfactorily, the main start up operation can begin.
  • Page 7 NOTE: Due to EMI’s ongoing product development program, all designs and specifications are subject to change without notice. CAH/W TECHNICAL DATA REFRIGERATION NUMBER OF CIRCUITS REFRIGERANT TYPE CABINET DIMENSIONS HEIGHT WIDTH DEPTH WEIGHT FASCIA DIMENSIONS HEIGHT WIDTH DEPTH WEIGHT CONNECTIONS...
  • Page 8 EMI CASSETTE DIMENSIONS SMALL CABINET • CAH 9,000 - 12,000 • CAHW 9,000 ONLY • CAF 8,000 - 12,000 • CAF4 8,000 ONLY ENVIROMASTER INTERNATIONAL LLC EMI@ENVIROMASTER.COM...
  • Page 9 • CAF4 12,000 - 20,000 LARGE CABINET • CAH/W 30,000 - 48,000 • CAF/4 33,000 - 36,000 CASSETTE DIMENSIONS (INCHES) SIZE MEDIUM 49¼ LARGE ENVIROMASTER INTERNATIONAL LLC EMI CASSETTE DIMENSIONS 1¾ 32¾ 32¾ 2¾ ½ 1¾ 32¾ 2¾ ½ Ø 5 3¼...
  • Page 10: Microprocessor Controller

    2. Red Timer/Alarm flashes once every 5 seconds - return air sensor failure. Refer to the Troubleshooting section of this manual for further instruction on dealing with alarms. BATTERY IR RE- SENSOR T1 = ROOM SENSOR T2 = DEFROST INPUT JUMPER EMI@ENVIROMASTER.COM...
  • Page 11 2ºF after 1 hour, 4ºF after 2 hours. SWING Causes the motorized air vanes to oscillate when selected (not applicable to all models). Switches the unit off (in certain instances the fan may be subject to a 2 minute run on time to dissipate residual heat). EMI@ENVIROMASTER.COM...
  • Page 12 NOTE: display will stop flashing after 15 seconds. 2. Repeat as per Monday - Friday (above). IMPORTANT: The built-intime clock provides ON/ OFF functionality. The time clock does not pro- vide occupied/unoccupied time control. Refer to the separate Infrared Controller manual for fur- ther details. EMI@ENVIROMASTER.COM...
  • Page 13: Control Circuit Checks

    EMI outdoor condensers will be manufactures with- out a low Volt transformer. When connecting an EMI evapo- rator to a non-EMI condenser, check to ensure that there is a 24V control transformer in either in the indoor unit or outdoor unit.
  • Page 14: Troubleshooting Section

    18” (See installation section of this manual for more information). BLOCKED/KINKED CONDENSATE PIPE. See section “Wa- ter Leaking From Unit.” WATER LEAKING FROM UNIT (See “Condensate High Level.”) CONDENSATE HIGH LEVEL (Red alarm LED on Micro Unit intervals.) EMI@ENVIROMASTER.COM...
  • Page 15 OUTDOOR UNIT TRIPPED – Refer to outdoor unit trouble- shooting section. INDOOR COIL TEMPERATURE TOO HIGH (MICRO UNITS ONLY) – Check refrigerant charge by measuring operating pressures. Check filter condition (See maintenance instruc- tions for more information). NO HEATING (HEAT PUMP) EMI@ENVIROMASTER.COM...
  • Page 16 Not Run”) Remove power from unit and reset manual overheat cut-out by rubbing. DO NOT PRESS!! Consult EMI technical support for instruction if necessary. HEATER ELEMENT FAILED – Investigate and replace if necessary. FAULTY HEATER RELAY – Check signals to relay and check action of relay contacts.
  • Page 17: Maintenance

    5. Gently vacuum clean the filters on a medium power vacuum. 6. Replace filters by reversing steps 2 to 4. NOTE: EMI recommends you keep at least one full set of cassette air filters as spares. FAN REMOVAL CAUTION: Isolate from the electrical supply before commencing work!! 1.
  • Page 18: Appendix A - Wiring Charts And Instructions

    2. Insert the stripped wire into the oval or round hole. 3. Remove screwdriver to allow the terminal block to “clamp down” on the wire(s). IT IS EXTREMELY IMPORTANT THAT THE WIRE(S) ARE CONNECTED PROPERLY OTHERWISE ARCING MAY RESULT IN ELECTRICAL DAMAGE OR FIRE! ENVIROMASTER INTERNATIONAL LLC EMI@ENVIROMASTER.COM...
  • Page 19: Appendix B - Exploded Unit Drawing And Parts List

    16. Fascia Assembly 17. Receiver (Microprocessor Version) 18. Terminal Rail, Relays & Timer (Micro & Electro-Mechanical Version) 19. Control Box Lid 20. Control Box 21. PCB Controller (Microprocessor Only) 22. Coil Support Brackets 23. Remote Handset (Microprocessor Only) ENVIROMASTER INTERNATIONAL LLC EMI@ENVIROMASTER.COM...
  • Page 20 15. Remote Handset 16. Control Box Lid 17. Control Box PCB 18. Control Box 19. Coil Bracket 20. Expansion Valve ENVIROMASTER INTERNATIONAL LLC Enviromaster International LLC 5780 Success Drive, Rome, NY 13440 Phone: 1-800-228-9364 / FAX: 1-800-232-9364 Email: emi@enviromaster.com Web: http://www.enviromaster.com EMI@ENVIROMASTER.COM...
