Trio G2 Instruction Manual

Hide thumbs Also See for TRIO G2:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Model G2
Instruction Manual
Congratulations on purchasing your Trio
Personal Media Player! To get the most out of your purchase, please take
the time to carefully read through this manual.
Foreword
If any problems occur during while using your Trio, please feel free to contact
Mach Speed technical support at 580-272-0035, or sending an email to
mssupport@machspeed.com.
Thank you for your support and cooperation!
Mach Speed Technologies bears no responsibility for any damage or loss of
personal data due to misuse of software and/or hardware, damage to the
player caused by human factors, replacement of battery, or other unforeseen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIO G2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trio TRIO G2

Summary of Contents for Trio TRIO G2

  • Page 1 Thank you for your support and cooperation! Mach Speed Technologies bears no responsibility for any damage or loss of personal data due to misuse of software and/or hardware, damage to the player caused by human factors, replacement of battery, or other unforeseen...
  • Page 2 circumstances. To prevent loss of your data, please backup your data regularly. Information in the manual is subject to change without notice and is subject to copyright protection. Copying or otherwise reproducing this material without prior written consent is prohibited. Due to Firmware changes, some of the pictures and functions described in this manual may not be the same as are included with your player.
  • Page 3 Caution Do not use the player in exceptionally cold or hot, dusty, damp or dry environments. Do not drop, strike, or throw your player. Physical damage to your player will void ALL warranties. Please charge your battery when Battery power icon shows an empty icon; The system automatically shuts down and the power is soon off when you switch on the unit once again;...

  • Page 4: Key Function

    Appearance Key Function Mode: press this button one briefly to return to the last screen, or press and hold to return to the main menu. Previous: in a menu, use this button to navigate to the previous item in the menu. In music or video mode, briefly press this button to skip to the previous file, or press and hold this button to rewind the current file.

  • Page 5: Power On/Off

    Power On/Off To power the player on, set the power switch to the ON position, and press and hold the PLAY button for 5 seconds, or until you see the loading and Trio screens. To power the player off, press and hold the PLAY button for 5 seconds, or until the device powers off, then set the power switch to the OFF position.
  • Page 6 1. Open Windows Media Player and connect the player to a working USB port. Windows Media player will prompt you with a setup screen asking you to name the MP3 player. 2. Once you have named your MP3 player, select Finish, and your Windows Media Player will open to the Sync tab.
  • Page 7 4. Windows Media player will load the songs on to your player. 5. Once all the songs you have added are synced to the unit, and Windows Media Player says that is safe to disconnect your MP3 player, disconnect the device. 7/18...
  • Page 8 COPY AND PASTE Note- This alternate method is used to load videos, pictures, and ebook files as well as audio files Connect the MP3 player to a working USB port. When the unit is connected to your computer, it will create a gray and green icon in the system tray (lower right hand corner of your desktop).
  • Page 9 Locate the music stored on your computer. Generally this is stored in the “My Music” folder of your computer. NOTE: if you are unable to locate the music on your computer, click on start, search, files and folders, then search for “*.MP3, *.WMA”. Once you have located the song files, you can right click on the song itself, and select “copy”.
  • Page 10 Repeat step 7 for as many songs as you want to copy on to the unit. NOTE: MAC Computers When connected to your MAC computer, the device will act as a removable drive. Simply drag your files to the device. Music On the main menu, highlight “Music”...
  • Page 11 Album: Displays a list of albums loaded on the player; once an album is selected a list of music from that album is displayed. Genre: Displays a list of genres loaded on the player; once a genre is selected, a list of music files will be displayed My Music List: Displays your 5 playlists.
  • Page 12 Music Submenu AB Repeat When you select “AB Repeat”, you will be returned to your file, and “A-” will be displayed on the playback screen. Briefly press PLAY to set the “A point” and “-B” will be displayed, briefly press PLAY again to set the B point, and begin playing you’re a-B selection.

  • Page 13: Video Submenu

    resolution of 220x176. Video menu Now Playing: return to the file you were playing previously (this option may not always be available Dir List: Lists all the video files saved in the Video folder of the device. Files are displayed in a standard folder structure. ->...

  • Page 14: Photo Camera

    On the main menu, highlight “Pictures” and briefly press the OK button to enter the picture mode. Please note that this player displays images in JPEG, BMP, GIF, TIF and PNG formats. ->Main Interface Now Playing: return to the file you were playing previously (this option may not always be available Dir List: Lists all the picture files saved in the Picture folder of the device.

  • Page 15: Video Camera

    Video camera On the main menu, highlight “video Camera” and briefly press the OK button to enter the video recording mode. Briefly press the OK button to start recording and press it again to pause. Briefly press the M button to exit, the system will automatically save the file before exiting.
  • Page 16 2) eBook Select eBook on the extra menu to enter the recording interface. eBook selection menu Now Playing: return to the file you were playing previously (this option may not always be available Dir List: Lists all the picture files saved in the Picture folder of the device. Files are displayed in a standard folder structure.
  • Page 17 year/month/day/time, etc, and use the Next or Previous buttons to adjust the value. 4) Stopwatch When in stopwatch mode, briefly press the OK button to start or pause a timer. Briefly press the Next button to stop the current timer, and begin timing on a second timer.
  • Page 18 Power Saving 1. Idle time Select how long the player is idle before powering off to conserve battery life. Choose Off, 10S, 30S, 1M, 1M, 5M or 10M. 2. Sleep Mode Set a timer to power off the device after a certain amount of time elapses, even if the player is playing a video or music.
