DVD1100
DVD1100
User Manual
Please read this User Manual carefully to ensure proper use of this
product and keep this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVD1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Curtis DVD1100

Summary of Contents for Curtis DVD1100

  • Page 1 DVD1100 DVD1100 User Manual Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.

  • Page 2: Table Of Contents

    Content Introduction Important Safety Instructions Caution Features Front Panel and Rear Panel Illustration Remote Control Connections TV set Connecting Digital Audio Connecting Advanced Features Function Operation SYSTEM setup Others Troubleshooting Specifications...

  • Page 3: Introduction

    Important Safety Instructions Introduction 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions. 8) Do not install near any heat sources such as radiations, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 4: Caution

    Please use the original box and packing materials for safe transportation of this product. It is normal for the cover and rear panel to become warm after the player has been operation for an extended period of time. Do not move this product during playback. Doing so may cause damage to the pickup and the disc.

  • Page 5: Front Panel And Rear Panel Illustration

    Front panel 9 10 SENSOR PREV BUTTON POWER CABIN DOOR OPEN/CLOSE BUTTON NEXT BUTTON BD LIGHT PLAY/PAUSE BUTTON VFD SCREEN STOP BUTTON Rear panel(2CH Audio output) 2 CH Audio output(L,R) COMPOSITE VIDEO output Component Video output (Y, Pb, Pr) Digital Audio COAXIAL output HDMI output Digital Audio OPTICAL output SERVICE(upgrade only)

  • Page 6: Remote Control

    Introduction Remote Control Remote Control OPEN/CLOSE STANDBY STANDBY OPEN/CLOSE AUDIO ANGLE SUBTITLE AUDIO ANGLE POP MENU/TITLE MENU RANDOM SUBTITLE POP MENU/TITLE RANDOM BONUS VIEW SECONDARY SECONDARY SECONDARY AUDIO MENU SUBTITLE AUDIO MOVE( COLOUR (RED, GREEN, YELLOW, BLUE) SETUP ENTER SECONDARY SUBTITLE STEP SETUP DISPLAY...

  • Page 7: Connections

    Connections HDMI VIDEO AUDIO IN VIDEO IN YPbPr IN HDMI IN CONNECT BD PLAYER TO TV SET BY AV CABLE Connect the BD player s L and R jack to the audio input jack on the TV. Connect the BD player s video out jack to the video input jack of TV. CONNECT THE BD PLAYER TO TV SET USING THE Y/Pb/Pr JACKS Use the COMPONENT Cable(not supplied) to connect BD player to your TV.

  • Page 8: Digital Audio Connecting

    Connections Connecting to an AV Amplifier with Digital Audio Input Coaxial Optical Digital Amplifier Notes: 1. Select the Coaxial or Optical digital audio output. 2. Set the digital Amplifier to the AV input connected to the BD player.

  • Page 9: Function Operation

    FUNCTION OPERATION Function Buttons OPEN/CLOSE To open the disc tray, press OPEN/CLOSE; To close the disc tray, press OPEN/CLOSE again. AUDIO During BD, DVD playback, press AUDIO can select different audio language. During VCD playback, press AUDIO button to switch between LEFT/RIGHT/STEREO channels.
  • Page 10 FUNCTION OPERATION NEXT During BD, DVD,CD or VCD playback, press NEXT toplay the next chapter, title or track. PREV During BD, DVD, CD or VCD playback, press PREV to play the previous chapter, title or track. Play In pause state or stop state, press the button, the player will be in playing state. MUTE Press MUTE to turn off the audio, press MUTE again to resume normal sound.
  • Page 11 FUNCTION OPERATION POP MENU/TITLE Press the button to enter the appointed title.(Requires disc support) During BD playback, press the button to display the disc s popup menu. REPEAT Each press of the REPEAT button will change the repeat mode. During VCD, CD playback, there are three modes: repeat Single, repeat ALL and Off. During BD, DVD playback, there are three modes: Repeat Chapter, Repeat Title and OFF.

  • Page 12: System Setup

    SYSTEM SETUP BD Player Setup Menu Press SETUP button on remote controller under STOP or TRAY OPEN status to enter Main menu. In Main menu, press UP/DOWN button to select desired sub-menus and press ENTER button to switch to other sub-menus. In sub-menus, LEFT/RIGHT button are used to change options for desired item which was be highlighted.
  • Page 13 SYSTEM SETUP 2. DISPLAY SETUP Select Video in the setup menu, and display the Video submenu: Display Menu TV Type NTSC TV Aspect 16:9 Resolution 1080P Color Space xvYCC Film Mode BACK To Index Menu ENTER: switch menu item : make choice 2.1 TV Type: Select TV type.
  • Page 14 SYSTEM SETUP 3. Audio setup menu Audio Menu Digital Output PCM Downsampling Dynamic Range Control BACK To Index Menu ENTER: switch menu item : make choice 3.1Digital Output Choose preferred option for digital output base on receiver connected to player PCM: Output PCM audio data for receiver not support Dolby and DTS decoding (mixed...
  • Page 15 SYSTEM SETUP 4. Parental control menu: Please Input 4-Digit parental password ENTER: switch menu item : make choice Enter right password to enter parental control menu. Parental Menu Parental Country Parental Control Parental Level 8.Adult Parental Password Default BACK To Index Menu ENTER: switch menu item : make choice Note: Factory default password is 6666.
  • Page 16 SYSTEM SETUP 4.4 Parental Password: Set parental password. Default: Reset to default password User Define: Setup user define password User defined password setting for parental control. Please set 4-Digit Parental password: ---- ENTER: switch menu item : make choice 4.5 BACK Select this item, then press ENTER to return to main setup menu.
  • Page 17 SYSTEM SETUP 6.File Disk Playback ----- WMA/MP3/JPEG(WMJ) files in disk After read out the device with WMJ files, player will list all directories and files in root directory as below picture shown. Press TITLE key to bring out help messages, press MENU key to bring up a pop up menu which guide you for special features, press LEFT button to exit pop up menu, press NAVIGATION buttons on remote controller to select desired item for playback or enter next level directory.
  • Page 18 SYSTEM SETUP For music files, in pop up menu, user can add current file into playlist as favorite songs, and set current file as background music while JPEG slide show. Play Add Play List Set As BGM For Playlist operation, in pop up menu, user can set play mode, audio mode, and remove songs which have been added into playlist.

  • Page 19: Troubleshooting

    Ensure you have entered the correct AV input for your TV. Ensure you have entered the correct AV input for your TV.

  • Page 20: Specifications

    Specifications Power requirements: AC 100-240 Volt, 50/60Hz Power consumption: 35W Discs COMPATIBILITY: BD,DVD,DVD+/-R/RW,VCD,CD-DA,CD-R/RW. Video out Video out: 1.0V(p-p)/75 , sync, negative polarity, RCA pin jack x 1 Audio out 2 channel out: RCA pin jackx2 Coaxial out: 0.5V(p-p)75 , RCA pin Jack x l Frequency response: 20Hz to 20kHz S/N ratio:>90dB Total harmonic distortion: <-65dB...
