Lightolier Lytespan 8277 Specification

Page 1 of 2
Ordering Information
Catalog No.
8277EWH
8277EBK
Features
1. Attachment Fitting: Molded polycarbonate integral color, fitting rotates
into track and locks on with push tabs.
2. Brass Contact: Extends for connection to 2nd circuit in Advent
track.
3. Electronic Ballast: .45 amps. Input power 54.
4. Reflector: Specular Plus
® * finish.
5. Track Adapter Housing: Die-cast aluminum.
6. Body: Extruded aluminum.
7. Louver Tabs: Molded in, snap into body, holds louver in place.
8. Louver with Parabolic Blades: Molded ABS, semi-specular finish.
9. Lamp Socket
10. End Cap: (2) Die-cast aluminum.
11. Pivot Tension Mount: 0° - 90° vertical rotation.
12. Pivot Tension Mount: 355° horizontal rotation.
13. Push Tab: Locks and detaches unit.
14. Ballast Housing: Die-cast aluminum.
15. (2) 24W/27W Twin Tube: Compact fluorescent lamps (by others).
16. Lamp Support Clip (2)
Electrical
2 Lt. Rapid start, high power factor, electronic ballast. Min. starting temp. 0°F.
Lampholder and ballast prewired with 105°C 18 ga. wire. Input voltage 120V.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0509
Lytespan
Mounting
All Lytespan Track Systems
DO NOT attach to stem mounted track
(unless used with suspension beam
housing) or track mounted with swivel
stem (7480, 7481) or wall mounted track.
Lytespan
®
Track Lighting System
®
Lyteflood
Finish Lamps
Matte White 2 Lt. 24W/27W Twin Tube Fluorescent
Matte Black PL-L24W by Philips
F27/24BX by GE
FT24DL by Osram Sylvania
Finish
All painted finishes baked enamel.
Labels
UL, I.B.E.W.
* Specular Plus is a registered trademark of MSC Laminates and
®
Composites Inc.
Advent is a registered trademark of Lightolier.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
8277
24 Compact Fluorescent
®
Type:
