A.
Individual Installation
1.
2.
3.
Figure 2
3"
Secure to Grid Using
Provided Clips. Provide
Power to Fixture Through
Access Plate and Test.
Lighting Systems
Figure 1
3"
Drop Fixture in 4" on
Center T Grid Opening.
And Hang Fixture from
Structure Above. Make
Sure Fixture is Leveled
Lengthwise and Width-
wise.
Clip
IS-CTS3_GRID
Install Diffuser Provided
with Fixture. Lens or
Louver
We reserve the right to change details of design, materials and finish.
Figure 3
3"
