Audio outputs
1/4" AUDIO OUTPUT (MAIN) L/MONO, R:
1/4" AUDIO OUTPUT (INDIVIDUAL) 1, 2
Output impedance
(L/MONO is 550 [Ω] for mono)
Maximum output level
L/MONO, R:
(INDIVIDUAL)1.2:
Load impedance
1/4" AUDIO OUTPUT HEADPHONE
Output impedance
Maximum output level
Load impedance
Audio inputs (if the separately sold EXB-SMPL option is
installed)
AUDIO INPUT 1, 2
LEVEL [MIC/LINE] switch, [LEVEL] knob
Input impedance: 10 [kΩ]
Nominal level
LINE +3 [dBu]
@ [INPUT] knob= min.
–30 [dBu]
@ [INPUT] knob= max.
MIC –18 [dBu]
@ [INPUT] knob= min.
–53 [dBu]
@ [INPUT] knob= max.
Maximum level
LINE +13 [dBu]
@ [INPUT] knob = min.
–20 [dBu]
@ [INPUT] knob= max.
MIC –8
[dBu]
@ [INPUT] knob= min.
–43 [dBu]
@ [INPUT] knob= max.
Source impedance: 600 [Ω]
Control inputs
DAMPER (half-damper supported), ASSIGNABLE
SWITCH/PEDAL
MIDI
MIDI IN, OUT, THRU, USB B connector
SD card slot
Usable media: 2.7–3.6 V (16 MB - 1 GB)
Other
AC power inlet, switch
Support for options
EXB-SMPL (one 16Mbyte 72-pin SIMM is included)
72-pin SIMM memory slots x 2 (for sample data RAM)
Dimensions (W × D × H)
61-key model: 1045 × 302 × 95 (mm)
76-key model: 1257 × 302 × 95 (mm)
88-key model: 1414 × 365 × 123 (mm)
Weight
61-key model: 7.8kg
76-key model: 9.2kg
88-key model: 24.1kg
Power consumption:
13W (if the EXB-SMPL option and two 32Mbyte SIMM
are installed)
1.1 [kΩ]
+12.0 [dBu]
+11.6 [dBu]
100 [kΩ] or greater
33 [Ω]
36 [mW]
33 [Ω]
Included items:
CD-ROM (KORG USB-MIDI driver, Voice Name List)
AC/AC power supply 9VAC 3.0A
Operating requirements for con-
nection to a computer
Windows
Operating system
Microsoft Windows XP Home Edition/Professional
Computer
A computer with USB connector that meets the above
requirements
Macintosh
Operating system
Mac OS X 10.2 or later
Computer
An Apple Macintosh with USB connector that meets
the requirements for the above operating system
Options
Expansion board
EXB-SMPL Sampling upgrade
Expression/volume pedal:
XVP-10 EXP/VOL pedal
Foot controller:
EXP-2
Damper pedal:
DS-1H
Pedal switch:
PS-1
Other:
MIDI cable
* Appearance and specifications of this product are subject to
change without notice. (Aug/05)
