Electrolux Z4700 Series Owner's Manual page 15

Problem
Motor will not start.
Motor suddenly stops.
Does not clean the carpet/floor.
No suction at the hose.
Noise from the brushroll area.
Cleaner is hard to push.
Cleaner height knob will not turn.
Brushroll will not turn.
Burning smell.
Stair brush doesn't work.
Missing parts.
More questions?
Cause
Electric Plug
Thermal Cut Off
Dust Cup
Filter
Belt
Brushroll
Hose
Dust Cup and Filter
Hose
Brushroll
Belt
Cleaner Height Setting
Cleaner Height Setting
Brushroll
Belt
Brushroll/Belt
Solution
• Push plug securely into outlet.
• Try another outlet.
• Check circuit breaker.
• Refer to page 3.
• Refer to page 13.
• Empty the dust cup.
• Make sure dust cup is installed properly and
dust cup latch is secured.
• Make sure pleated filter is clean.
• Replace broken, loose, out-of-shape belt.
• Clean hair and thread from bristles and end
cap area.
• Replace brushroll if bristles are worn.
• Remove any clogs from the hose that restrict
the air flow.
• Refer to pages 11, 12, and 13.
• Empty the dust cup.
• Clean and install filter properly.
• Make sure dust cup is installed properly and
dust cup latch secured.
• Remove any clogs from the hose that restrict
the air flow.
• Check both ends of the hose.
• Refer to pages 11 and 13.
• Remove hood and clean debris from the
brushroll area.
• Replace broken, loose, out-of-shape belt.
• Refer to page 12.
• Put handle in operating position. Tilt the
cleaner back to raise the front wheels off the
floor. Then turn the knob to a higher setting.
• Refer to page 9.
• Hint: Put handle in operating position. Tilt the
cleaner back to raise the front wheels off the
floor. Then turn the knob.
• Replace broken, loose, out-of-shape belt.
• Refer to pages 9 and 12.
• Remove hood and clean debris from the
brushroll area.
• Refer to page 12.
• Remove hood and clean debris from the
brushroll and belt area.
• Refer to page 12.
• Remove any clogs from the opening or debris
around the brushroll or belt.
• Refer to page 14.
• Call Electrolux on 08445 614614. Call to this
number will be charged at 5p per minute
at all times from a BT Landline. Have the
model and serial numbers ready when you
call. See rating plate beneath the cleaner.
15
