diagram).
required at the back of the barbecue between the
splashback and the bench cut-out of 73mm minimum.
This is to allow clearance for the hood to open.
warning
indicated below must be allowed for. A suitable grille can
be fitted if desired. This vent area is to allow air into the
enclosure for the correct combustion of gases and for
the correct exhausting of the products of combustion. In
the case of LPG the gas is heavier than air, this vent in
the situation where there may be a leak allows the gas to
escape from the enclosure. This vent must be
700mm x 25mm minimum and positioned centrally
135mm below the mounting surface. (see diagram).
bench width 600mm min.
553mm
bench
464mm
553mm
538mm
600mm min.
135mm
25mm
700mm
Island style installation
(example shown with barbecue with slimline line)
42mm
bench
177mm
73mm min.
25mm
from cut-out
minimum clearance to back wall
943mm
1058mm
1025mm cut-out
1025mm x 502
cut-out
electrolux integrated barbecue installation instructions 7
589mm
562mm
538mm
bench
464mm
538mm
600mm min.
135mm
502mm
25mm
cut-out
Installation in a bench with splashback
(example shown with barbecue with roasting hood)
211mm
bench
177mm
25mm
minimum clearance to back wall
925mm
526mm
1058mm
splashback
1025mm cut-out
1025mm x 502
cut-out
700mm
453mm 601mm
56mm
73mm min.
from cut-out
502mm
cut-out
