Normal Operating Sounds

·
You may hear faint gurgling or bubbling sounds
when the refrigerant is pumped through the coils
or tubing at the rear, to the cooling
plate/evaporator.
·
When the compressor is on, the refrigerant is

Maintenance and Cleaning

Removing the ventilation grille

The ventilation grille can be removed, e.g. to wash
the grille.
Make sure the door is open when removing the
ventilation grille. Unsnap the upper edge of the grille
by pulling outward/downward. Then pull the grille
straight out to completely remove it.

Internal Cleaning

Clean the inside and the accessories with warm
water and bicarbonate of soda (5 ml to 0,5 litre of
water).
Rinse and dry thoroughly.
Do not use detergents, abrasive
powders, high perfumed cleaning
products, wax polishes or cleaning
products containing bleach or alcohol .
Regulary check the door seals and wipe clean to
ensure they are clean and free from debris.
Clean out the drip channel inside the fridge at
regular intervals and ensure that the drip channel is
clear at all times. If blocked carefully clear using a
piece of flexible curtain wire inserted into the drain
outlet to remove the blockage.

External Cleaning

Disconnect the appliance from electricity supply.
Wash the outer cabinet with warm soapy water.
Remove the ventilation grille (see the section
"Removing the ventilation grille") and vacuum-clean
under the cabinet. Once or twice a year dust the
condenser (black grille) and the compressor at the
back of the appliance, with a brush or vacuum
cleaner, as an accumulation of dust will affect the
performance of the appliance and cause excessive
electricity consumption.
When moving the cabinet, lift it by
the front edge to avoid scratching
the floor.

Defrosting the fridge

The fridge is defrosted automatically every time the
compressor stops. Frost formation can be prevented
by:
· not putting warm foodstuff inside the cabinet.
· avoiding frequently opening the door or keeping
it open too long.
· not placing foodstuffs directly against the cold
cooling plate.
being pumped round, and you will hear a
whirring sound or pulsating noise from the
compressor.
·
A thermostat controls the compressor and you
will hear a faint " click" when the termostat cuts
in and out.
