1990-92
USA Built
R GN81-50-681
L GN81-50-691
Japan Built
Black
R G212-50-681
L G212-50-691
Body Color¶
R G243-50-681-04
L G243-50-691-04
¶Black/Silver listed, Order by Application
UC Crystal White/Silver; PZ Brilliant Black/Silver;
SQ Blaze Red/Silver; 6L Graceful Red/Silver;
NU Vintage Red/Silver; 6S Exceed Green/Silver;
5N Brave Blue/Silver; 1H Steel Gray/Silver;
3L Silver Stone M/Silver
3 Mudguard
R G211-51-840
L G211-51-850
4 Rivet (2/Side)
R/L B092-51-833
5 Grommet
R/L G030-51-852
Tray, Battery
BG62-56-032A
Support, Tray
GJ21-56-040A
Clamp, Battery Hold-Down
GJ21-56-03XA
Bolt, Clamp
Front
0259-54-292A
Rear
0613-65-857A
FRONT INNER STRUCTURE
FRONT
1 Support Assy, Radiator
USA Built
To 12-4-89
GJ21-53-100K
From 12-4-89
GN98-53-100
Japan Built
GJ21-53-100K
2 Bar, Upper Tie¶
1988-89
GJ21-53-150C
1990-92
USA Built
GJ21-53-150C
Japan Built
GJ21-53-150C
3 Panel, Side¶
USA Built
To 12-4-89
R GJ21-53-120E
L GJ21-54-120D
From 12-4-89
R GN98-53-120
L GN98-54-120
Japan Built
R GJ21-53-120E
L GJ21-54-120D
4 Bar, Lower Tie¶
USA Built
To 12-4-89
GJ21-53-16XD
From 12-4-89
GN98-53-16X
Japan Built
GJ21-53-16XD
¶Included w/Radiator Support Assy
5 Support, Latch
GJ21-56-220B
6 Bracket, Lamp
R GJ21-52-140A
L GJ21-52-240A
SIDE
1 Apron Assy
R GJ22-53-200
L GJ22-54-200
2 Panel, Apron¶
R GJ22-53-210F
L GJ22-54-210E
3 Frame, Side¶
USA Built
To 11-3-89
R GJ21-53-300R
L GJ21-54-300P
From 11-3-89
R GJ21-53-300R
L GJ21-54-300P
madpl1_g01_
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax 1-888-256-7969 or 858-549-0629.
Page 145—April 22, 2004—13:31:44—Version
Japan Built
¶Included w/Apron Assy
4 Reinf, Upper Apron
5 Reinf, Lower Apron
6 Brkt, Hinge Stop
7 Plate, Apron Seal
8 Guard, Splash
1988-89
w/Turbo
Man Trans
Auto Trans
w/o Turbo
1990-92
USA Built
w/Turbo
To 12-4-89
From 12-4-89
w/o Turbo
Japan Built
9 Bracket, Engine Mount

CRUISE CONTROL SYSTEM

1 Actuator, Cruise
w/Turbo
w/o Turbo
2 Brkt, Actuator Mtg
3 Brkt, Actuator Front
4 Brkt, Actuator Rear
5 Mount, Rubber (3)
6 Cable, Cruise
w/Turbo
w/o Turbo
7 Control Unit, Cruise
w/Turbo
w/o Turbo

ABS/BRAKES

1 Sensor, ABS Wheel
-See Front or Rear Suspension Section
2 Actuator, ABS
USA Built
To 10-2-91
From 10-2-91
Japan Built
3 Brkt, Actuator
USA Built
To 10-2-91
From 10-2-91
Japan Built
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
R GJ21-53-300R
L GJ21-54-300P
R GJ21-53-281D
L GJ21-54-281D
R GJ21-53-291A
L GJ21-54-291A
R GJ21-53-575B
L GJ21-54-575B
R/L G217-56-381A
R GJ21-56-330D
L GJ21-56-341A
R GJ21-56-330D
L GJ27-56-341A
R GJ21-56-330D
L GJ21-56-341A
R GJ21-56-330D
L GJ27-56-341A
R GN98-56-330
L GJ27-56-341A
R GJ21-56-330D
L GJ21-56-341A
R GJ21-56-330D
L GJ27-56-341A
M001-53-370A
GN55-66-310C
GN51-66-312
GJ21-66-31Y
GN51-66-3A1B
GN51-66-3A8B
F285-13-363
GN55-66-311
GJ21-66-311B
GN55-66-320
GN51-66-320
KA11-43-7A0C
GN90-43-7A0C
GJ55-43-7A0C
GJ55-43-310B
GN90-43-310A
GJ55-43-310B
MAZDA 626 1988-92

WHEEL

STEEL WHEEL
Wheel, Steel
1 Black
9965-84-5540
2 Silver
9965-86-554
3 Wheel, Spare
9965-10-4050
Cover, Wheel
1988-89
4
w/Hub Nut Holes
G214-37-170B
5
w/o Hub Nut Holes
GJ25-37-170
1990-92
6
Type A
GN51-37-170A
7
Type B
GJ29-37-170
Stem, Valve
9963-60-4130
ALUMINUM WHEEL
Wheel Assy, Aluminum
1 Style 1
8BG1-37-600
2 Style 2
8DG8-37-600
3 Style 3¶
R 8DG3-37-600
L 8DG4-37-600
4 Style 4
8BGU-37-600
5 Style 5
8DG9-37-600
¶Silver listed, Order by Application
Cap, Center (a)
6 Style 1
G213-37-191A
7 Style 2
B004-37-192
8 Style 3¶
GJ23-37-191A
9 Style 4
H115-37-192
10 Style 5
USA Built
GN82-37-191A
Japan Built
GN52-37-191A
¶Silver listed, Order by Application
Stem, Valve (a)
9963-60-4130
(a) Included w/Wheel Assy
Wheel, Spare
9965-10-4050

FRONT SUSPENSION

Illustration Located in Next Column
1 Hub
2 Wheel Disc Brakes
R/L GJ51-33-060A
4 Wheel Disc Brakes
R/L GJ55-33-060A
