MODEL : AOÜR30LC,AOÜR30LF
„ „
Muffler
Pressure
switch
Cooling
Heating
Refrigerant pipe diameter
Liquid : 3/8" (9.52 mm)
Gas : 5/8" (15.88 mm)
Heat exchanger
3-Way
valve
(Large)
4-Way valve
- (02 - 06) -
( INDOOR )
Heat exchanger
( OUTDOOR )
3-Way
valve
(Small)
Strainer
Expansion valve
Strainer
