Akura AOP02STB User Manual

Digital terrestrial free to view receiver

Advertisement

Quick Links

Safety
Congratulations on purchasing this Digital Terrestrial Free to View Receiver.
Please note that the availability of digital signals depends on the transmitter(s) available in
your reception area.
In order to enjoy this product for a long time it is important that you observe the following
points when installing and operating the receiver:
• This receiver should be plugged into a 230V to 240V AC, 50/60Hz power supply only.
• This receiver is intended for the reception of TV picture and sound signals.
• Avoid long-term display of static images e.g. menus or audio only channels. Use the
Radio feature (blank screen – see Advanced Setup).
• The receiver is intended for use in dry rooms. Do not expose the receiver to any moisture.
If there is a need to use the receiver in open air, make sure that it is protected against
moisture (rain, humidity, splashes etc.).
• Do not place any object filled with water such as a vase on the receiver.
• Place the receiver on a hard and flat surface and do not place any object over it.
• If the receiver is placed in an enclosed unit, make sure that there is at least 10cm of
space around the receiver and the sides of the unit.
• Do not place the receiver close to a heat source or in direct sunlight as this will prevent
the necessary cooling for the unit.
• During a thunderstorm it is advised to disconnect the unit from the mains and from the
aerial to prevent damage from lightning.
• Never open the receiver as this will invalidate your guarantee.
• Dispose of used batteries at appropriate collection points and not in the normal waste
– this prevents hazardous chemicals from the batteries being released into the
environment.
• If the receiver is not to be used for a long period such as on holiday. Disconnect from the
power and aerial system.
• Do not connect or modify cables with the receiver plugged in.
• No naked flame sources such as lighted candles should be placed on the apparatus.
• The mains plug is used as the disconnect device and it shall remain readily operable.
To completely disconnect the power input, the mains plug of the apparatus should be
disconnected from the mains (when the mains plug is disconnected the power indicator
light will not light up).
Note
Dust will collect on the receiver and can be removed by using a dry clean cloth. Do not
spray any substances such as cleaning liquids on the unit.
Akura manual rev.indd 1
1
15/8/2005 14:51:40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AOP02STB and is the answer not in the manual?

Questions and answers

Summary of Contents for Akura AOP02STB

  • Page 1 Note Dust will collect on the receiver and can be removed by using a dry clean cloth. Do not spray any substances such as cleaning liquids on the unit. Akura manual rev.indd 1 15/8/2005 14:51:40...
  • Page 2: Table Of Contents

    Basic Operations First Time Tuning Programme Information Lists and Interactive Services Advanced Operations Tuning the Receiver Languages and TV Setup Parental Control Timer Programming and Recording Upgrading Your Receiver Technical Information Display Troubleshooting Guide Specifications Akura manual rev.indd 2 15/8/2005 14:51:40...
  • Page 3: Parts Checklist

    Unpack your receiver and make sure that you have all of the items listed below. Digital Terrestrial Free-to-View Receiver Remote Control Scart Cable Two AAA batteries Instruction Book Note If any item from the checklist is missing please notify your sales agent where you purchased this receiver. Akura manual rev.indd 3 15/8/2005 14:51:51...
  • Page 4: About Your Receiver

    About Your Receiver Front Rear Akura manual rev.indd 4 15/8/2005 14:51:53...
  • Page 5: Getting Started And Connections

    AV may be necessary). If you need to connect other boxes such as a DVD player, connect the DTR box as Fig 2 and your DVD player to AV1 on the Tv. Akura manual rev.indd 5 15/8/2005 14:51:56...
  • Page 6 Place batteries into remote control as shown. Plug your receiver into the mains supply. To mains supply Note Always disconnect the receiver from the mains supply before you connect it to any other equipment. Akura manual rev.indd 6 15/8/2005 14:52:00...
  • Page 7: Remote Control

    Channel – navigates through channel and favourites Switches between TV and Radio. The following keys are for PPR only and do not function with this STB. They do not function on this set top box. Akura manual rev.indd 7 15/8/2005 14:52:01...
  • Page 8: Basic Operations

    “Advanced Operations” section. Note To learn about other advanced settings such as “Parental Control,” “TV Setup” “Language,” “Setting your PIN” and “Timer Programming and Recording” refer to the “Advanced Operations” section. Akura manual rev.indd 8 15/8/2005 14:52:02...
  • Page 9: Programme Information

    You are able to view the current programme • To view details of the next programme press the right navigation button. • To view more details of the current programme press [ ] again. Akura manual rev.indd 9 15/8/2005 14:52:04...
  • Page 10: Lists And Interactive Services

    • Press [Menu] on the remote and then select “Favourites” and press [OK]. • To create a new Favourite list press the [Green] button. • To edit the contents of your favourite list press the [Yellow] button. Akura manual rev.indd 10 15/8/2005 14:52:04...
  • Page 11 • To enter into “Text” mode press [Text] on the remote. • To return to normal viewing press [Text] again. Note Channels that offer Teletext will also provide details on how to use the interactive features on the screen. Akura manual rev.indd 11 15/8/2005 14:52:05...
  • Page 12: Advanced Operations

    The “Full Scan Add New Services” option will add new channels that are available to your receiver whereas the “ Full Scan Replace Existing Services ” option will replace the current channel settings and scan for new ones. Akura manual rev.indd 12 15/8/2005 14:52:05...
  • Page 13 ¼, 1/8, 1/16 and 1/32. • Select the option of choice and use the right and left navigation buttons change the values for scanning. Select the “Scan” option and press the right navigation button Akura manual rev.indd 13 15/8/2005 14:52:06...
  • Page 14 In order to reset the ex factory state: select the main menu and press 0000 Note The default settings are set for the UK DTT network, which are ‘Yes’ for 2K transmission mode and 1/32 guard interval. Akura manual rev.indd 14 15/8/2005 14:52:06...
  • Page 15: Languages And Tv Setup

    • The UHF signal from the aerial is also available from the adjacent connector to enable a VCR or Tv to be connected as shown on page 5 (Loop through). • Press [Exit] to save changes and exit this menu. Akura manual rev.indd 15 15/8/2005 14:52:07...
  • Page 16: Parental Control

    You can choose to block all programmes by selecting “Block,” or set blocks for ages 18+, 15+, 12+ or 6+. You may turn off age blocking by selecting “Off.” Akura manual rev.indd 16 15/8/2005 14:52:07...
  • Page 17 Note Programmes being aired all have an age rating for censorship and they will be compared to the parental control setting it has been set up. For programmes for which age blocking Akura manual rev.indd 17 15/8/2005 14:52:08...
  • Page 18: Timer Programming And Recording

    • If the program includes subtitles and you would like to record them select “ Yes ” in the “ Subtitles ” option. Otherwise, choose “No.” • Press [ OK ] to save entry. Akura manual rev.indd 18 15/8/2005 14:52:09...
  • Page 19: Upgrading Your Receiver

    • Select “Check for Downloads” and press [OK]. • If no download is available press [Exit]. Note It is recommended that you keep your receiver up to date. During a download DO NOT switch off the receiver. Akura manual rev.indd 19 15/8/2005 14:52:09...
  • Page 20: Technical Information Display

    • Press [Menu], select “Setup” and press [OK]. • Select “Technical Information” and press [OK]. Note It is recommended that you keep your receiver up to date. During a download DO NOT switch off the receiver. Akura manual rev.indd 20 15/8/2005 14:52:09...
  • Page 21: Troubleshooting Guide

    Messed up the tuning • Reset the original new condition. • Select “ Menu” • Press 0000 If you still experience difficulty, please call the Technical Help Line 01422 203676 ( normal rates apply). Akura manual rev.indd 21 15/8/2005 14:52:10...
  • Page 22: Specifications

    RF Loop Through Connector IEC Type Male SCART Power Supply Power Inlet AC 230 – 240 V ~ 50/60Hz Power Consumption 10 W Due to ongoing developments to improve the product the specification may change during manufacture. Akura manual rev.indd 22 15/8/2005 14:52:10...
  • Page 23 When this appliance has reached the end of its useful life. It must be disposed of in accordance with local by-laws. Consult our local waste disposal authority. ( WEEE Directive ) Akura manual rev.indd 23 15/8/2005 14:52:10...
