Audio I/O Connections - Asus P8P67 PRO User Manual

* LAN port LED indications
Activity Link LED
Status Description
OFF No link
ORANGE Linked
BLINKING Data activity
** Bluetooth dongle LED indications
Activity Link LED
Status
OFF
Blue
BLINKING
***Audio 2, 4, 6, or 8-channel configuration
Port Headset
2-channel
Light Blue Line In
Lime Line Out
Pink Mic In
Orange –
Black –
Gray –
2.3.11

Audio I/O connections

Audio I/O ports
Connect to Headphone and Mic
2-44
Speed LED
Status Description
OFF 10 Mbps connection
ORANGE 100 Mbps connection
GREEN 1 Gbps connection
Description
No link
Linked
Data activity
4-channel 6-channel
Line In Line In
Front Speaker Out Front Speaker Out
Mic In Mic In
– Center/Subwoofer
Rear Speaker Out Rear Speaker Out
– –
ACT/LINK SPEED
LED LED
LAN port
8-channel
Line In
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
Side Speaker Out
Chapter 2: Hardware information
