CARE OF MOTOR FILTER
The motor filter protects the motor from dirt and ensures long-lasting and efficient
operation.
When the filter becomes dirty, wash it in warm water, dry it thoroughly, and position
it in place.

REPLACING THE MICROFILTER

• The microfilter filters the air which comes out from the vacuum cleaner.
• To open the filter cover, press down and pull it simultaneously.
• Remove and replace the dirty microfilter.
• Close the cover.

TROUBLESHOOTING

PROBLEM
Motor does not start
Suction force is gradually
reduced
Cord does not rewind fully
Page 12
CAUSE
No voltage
Filter,nozzle,suction hose
tube blocked, or bag full.
Check that the cord is
not twisted or wound
unevenly
-10
EN
REMEDY
Check cable, plug and
socket.
Remove the obstruction
or replace bag.
Pull the cord out 6~10ft
& push down the cord
rewind button
