Using The Assemble Edit Function; Recording From Another Vcr Or Camcorder; Audio Dubbing A Pre-Recorded Cassette; Using The Tv Buttons On The Remote Control - Samsung Sv-M35K Instruction Manual

Using the Assemble Edit Function

This function allows you to start a new recording at a
specific position on the cassette while maintaining a
very smooth scene change
1 Insert the cassette to be edited in your VCR.
2 Press the button to start playback.
❿ll
3
When you reach the position from which you wish
to start the new recording, press the ❿ll button.
4 F.ADV
Press the F.ADV ( ) button again as often as
necessary to advance frame by frame, until the
exact recording position is located.
5
While the VCR is in still mode, hold the REC button
down for a while to activate the Assemble Edit
function.
Result: Record symbol flashes in the display.
6 Select the source from which you wish to record by
pressing:
The PROG/TRK ( or ❷ )/ PROG ( or ❷ )
buttons for television channels
The INPUT button for the LINE IN 1 or LINE IN
2 input sources
7
Press the ❿ll button to start recording.
8
When you have finished recording, press .
Recording from Another VCR or
Camcorder
You can copy a cassette to your VCR from another
video source, such as another VCR or a camcorder.
It is an infringement of copyright laws to
copy prerecorded cassettes or to re-record
them in any form without the permission of
the owners of the corresponding copyright.
1 Connect the VCR, from which the cassette is to be
copied, to the appropriate RCA audio and video
input connectors on the rear of your VCR, as
indicated on page 12.
You can also use an RCA audio and video cable to
connect the LINE IN 2 input on the front of your
VCR.
2
Insert a blank cassette in your VCR.
3
Insert the pre-recorded cassette in the other video
source (VCR or camcorder).
4
Press the INPUT button to select the appropriate
input on your VCR:
LINE IN 1 for the rear input
LINE IN 2 for the front input
5
Start playing back the cassette to be copied.
6
Hold REC down for a while to start recording on
your VCR.
7
When you have finished recording, press
both VCRs.
If you wish to view the cassette being copied:
Your VCR must be connected as usual to the
television (see page 8~9 for further details)
ENG-26
Audio Dubbing a Pre-recorded
Cassette
(SV-M625K Only)
With the Audio Dubbing function, you erase the
previously recorded sound and replace it with a new
soundtrack from:
A CD player
A microphone connected to a sound system
A cassette player
Restriction:
Audio dubbing is applicable only to the longitudinal
audio track (normal audio).
1 Connect an RCA audio cable to the appropriate
output on your sound system (CD/cassette player
for example).
2
Connect the other end of the RCA audio cable to
the audio input connectors (L, R) on the front of
your VCR.
3
Insert the pre-recorded cassette on which the audio
track is to be replaced, and press the
playback.
4
Find the scene that you want to over-dub and press
❿ll on the remote control.
5
Press DUB.
Result: Your VCR is now in the Audio dubbing
Pause mode.
6
On the sound system, locate the point on the CD or
cassette at which you wish to start playback.
on
Example: The track that you wish to record on the
cassette.
7
When you are ready:
Start playback on the sound system
Press REC on the remote control.
Result: The soundtrack is replaced on the pre-
recorded cassette.
The new sound will be recorded on the normal
sound track of the tape, and the original sound will
remain on the Hi-Fi sound track.
To hear the new sound and original sound mixed
together, press the Audio button on the remote
control until the MIX option is displayed (see page
21).
Using the TV Buttons on the Remote
Control
(SV-M625K/SV-M85K Only)
Your VCR remote control will work with Samsung
televisions and compatible brands.
To determine whether your television is compatible,
follow the instructions below.
1 Switch your television on.
2 Point the remote control towards the television.
3
Hold down the TV button and enter the two-figure
code corresponding to the brand of your television,
by pressing the appropriate numeric buttons.
Brand Codes Brand
SAMSUNG 01 to 06 PHILIPS
AKAI 09, 23 SABA
GRUNDIG 09, 17, 21 SONY
LOEWE 02 THOMSON 13, 14, 24
PANASONIC 08, 23 to 27 TOSHIBA 07, 16 to 19, 21
to start
❿ll
Result: If your television is compatible with the
remote control, it is switched off. It is now
programmed to operate with the remote
control.
If several codes are indicated for your
television brand, try each one in turn until you
find one that works.
When you change the batteries in the remote
control, you must reprogramme the code,
following the same procedure.
You can then control the television using the following
buttons.
Button Function
TV STANDBY/ON Used to switch the television on
and off.
TV or VCR Used to switch between th TV
and VCR modes. Only the VOL
(+ or –) and TV STANDBY/ON
buttons are operational in VCR
mode. -/-- Used to enter a two-
figure programme number.
Example: For programme 12,
INPUT Used to select an external
source.
VOL + or – Used to adjust the volume of
the television.
PROG/TRK Used to select the required
( or ) programme.
❷
DISP./ Used to switch between an
external source and the television
The various functions will not necessarily work on
all televisions. If you encounter problems, operate
the television directly.
ENG-27 ENG-27
Codes
02, 20, 22
13, 14, 22 to 24
15, 16
press -/-- followed by
numeric buttons 1 and 2.
