Specifications

Specifications subject to change without notice.
Audio Section
Max Power Output ...............................................................................................................................................................................................400 W
Rated Power Output
Normal (4 Ω) (20 Hz – 20 kHz, 0.08 % THD) ...................................................................................................................................35 W x 4
Normal
(4 Ω) (DIN : 45324 , +B = 14.4V) ..........................................................................................................................................35 W x 4
Normal
(2 Ω) (1 kHz, 0.8 % THD) ...........................................................................................................................................................50 W x 2
Bridged (4 Ω) (1 kHz, 0.8 % THD) ....................................................................................................................................................... 100 W x 2
Frequency Response (+0, –3 dB) .............................................................................................................................................. 10 Hz – 45 kHz
Sensitivity (rated output) (MAX.) ..................................................................................................................................................................... 0.2 V
Sensitivity (rated output)
Signal to Noise Ratio ........................................................................................................................................................................................... 100 dB
Input Impedance .....................................................................................................................................................................................................10 kΩ
Low Pass Filter Frequency (12 dB/oct.) .................................................................................................................. 50 – 200 Hz (variable)
High Pass Filter Frequency (12 dB/oct.) ................................................................................................................. 50 – 200 Hz (variable)
General
Operating Voltage .................................................................................................................................................. 14.4 V (11 – 16 V allowable)
Current Consumption .............................................................................................................................................................................................25 A
Dimensions (W x H x D) .........................................................................................................................................................330 x 59 x 242 mm
............................................................................................................................................................................................
Weight .........................................................................................................................................................................................................3.0 kg (6.6 lbs)
CEA-2006
RMS Watts per channel @ 4 ohms < 1 % THD+N ......................................................................................................................40 W x 4
RMS Watts per channel @ 2 ohms < 1 % THD+N ......................................................................................................................50 W x 4
(MIN.) ...................................................................................................................................................................... 5.0 V
13 x 2-5/16 x 9-8/16 inch
English
13
