WALL MOUNTING INSTRUCTIONS
3. To install the hook to the dryer, remove the 2 screws and 2
corks as indicated in Fig. 1.
4. Align hooks as shown in Fig. 2 and each hook should be fixed
up well with three screws. Install the spacers provided as Fig. 2
10
2 screws
2 corks
Fig. 1
.
Hooks
3 screws
Spacers
Fig. 2
WALL MOUNTING INSTRUCTIONS
5. With assistance, mount dryer on wall brackets. See Fig. 3
6. A new control panel film with inverted symbols supplied. Peel the
release paper from the back of inverted film then place the film on
the surface so that writing is the correct way up .
150min
200min
100min Warm HDY60M
Cool
HDY60M
OFF
60min
30min
60min
20min
OFF
150min
200min
100min
OFF
60min
30min
60min
20min
OFF
Fig. 3
