SHED ASSEMBLY - HEADERS
20
Place rear header (K) over back walls and fit four
protruding support legs into pockets molded in back
walls. Secure rear header using eight screws (X).
AND TRUSS
x2
JJ
18
Place front header (J) over door opening and fit four
protruding support legs into pockets molded in front
corners. Secure front header using two screws (X).
22
Raise ridge beam (P) up and into rear header (K). Raise
ridge beam (P) up and into rear header (K). Secure with
one bolt (HH) and one nut (JJ). DO NOT tighten. Repeat
for front header (J). Note: Header panels may need to
be pushed inwards or outwards slightly as ridge beam is
slid into place.
