SERVICE MANUAL

Regarding service information other than these sections, refer to the service manual No. 86693 (GR-DVL145EG-X).

Also, be sure to note important safety precautions provided in the service manual.

SPECIFICATIONS

Camcorder

Power supply

: DC 11.0 V

DC 7.2 V

Power consumption

LCD monitor off, viewfinder on : Approx. 4.3 W

LCD monitor on, viewfinder off : Approx. 5.3 W

Dimensions (W x H x D)

: 83 mm x 94 mm x 223 mm

(with the LCD monitor closed and the viewfinder pushed down)

Weight

: Approx. 630 g

Operating temperature

: 0°C to 40°C

Operating humidity

: 35% to 80%

Storage temperature

: –20°C to 50°C

Pickup

: 1/4" CCD

Lens

: F 1.6, f = 3.9 mm to 62.4 mm, 16:1 power zoom lens

Filter diameter

: ø40.5 mm

LCD monitor

: 2.5" diagonally measured, LCD panel/TFT active matrix system

Viewfinder

: Electronic viewfinder with 0.24" black/white LCD

Speaker

: Monaural

Digital Video Camera

Format

: DV format (SD mode)

Signal format

: PAL standard

Recording/Playback format

: Video: Digital component recording

: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),

48 kHz 2-channel (16-bit)

Cassette

: Mini DV cassette

Tape speed

: SP: 18.8 mm/s

LP: 12.5 mm/s

Maximum recording time

: SP: 80 min.

(using 80 min. cassette)

LP: 120 min.

Connectors

S-Video

: Y: 1 V (p-p), 75 Ω, analogue

Output

C: 0.29 V (p-p), 75 Ω, analogue

: 1 V (p-p), 75 Ω, analogue

Video output

Audio output

: 300 mV (rms), 1 kΩ, analogue, stereo

Output

: 4-pin, IEEE 1394 compliant

DIGITAL VIDEO CAMERA

GR-DVL145EK,

GR-DVL149EG-X

(The specifications shown pertain specifically to the model GR-DVL145.)

General

(Using AC Adapter)

(Using battery pack)

This service manual is printed on 100% recycled paper.

AC Adapter

Power requirement

: AC 110 V to 240 V , 50 Hz/60 Hz

Output

: DC 11 V

, 1 A

Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to

change without notice.

GR-DVL145EK, GR-DVL149EG-X M2D122

No.86726

2002/12

Need help?

Do you have a question about the Mini DV Pal GR-DVL145EK and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC Mini DV Pal GR-DVL145EK

Page 1 SERVICE MANUAL DIGITAL VIDEO CAMERA GR-DVL145EK, GR-DVL149EG-X Regarding service information other than these sections, refer to the service manual No. 86693 (GR-DVL145EG-X). Also, be sure to note important safety precautions provided in the service manual. SPECIFICATIONS (The specifications shown pertain specifically to the model GR-DVL145.) Camcorder AC Adapter Power requirement...
Page 2 TABLE OF CONTENTS DIFFERENT TABLE................1 The following table indicates different parts number between models GR-DVL145EG-X, GR-DVL145EK and GR-DVL149EG-X. PACKING AND ACCESSORY ASSEMBLY<M1> MODEL GR-DVL145EG-X GR-DVL145EK GR-DVL149EG-X ITEM PACKING CASE LY32746-001A *LY32746-001B POLY BAG QPA02003506 YQM30061-3 QPA02003506 INST. BOOK(GE) LYT1023-002A LYT1089-001A —...
Page 3 SERVICE MANUAL DIGITAL VIDEO CAMERA GR-DVL145EG SPECIFICATIONS (The specifications shown pertain specifically to the model GR-DVL145EG/EK) Camcorder Connectors S-Video General : Y: 1 V (p-p), 75 Ω, analogue Output C: 0.29 V (p-p), 75 Ω, analogue Power supply : DC 11.0 V (Using AC Adapter) DC 7.2 V (Using battery pack)
Page 4 TABLE OF CONTENTS Section Title Page Section Title Page Important Safety Precautions 3. ELECTRICAL ADJUSTMENT 3.1 PRECAUTION ............... 3-1 INSTRUCTIONS 3.2 SETUP .................. 3-2 1. DISASSEMBLY 1.1 BEFORE ASSEMBLY AND DISASSEMBLY ......1-1 1.1.1 Precautions ..............1-1 4. CHARTS AND DIAGRAMS 1.1.2 Assembly and disassembly ..........
Page 5 Important Safety Precautions Prior to shipment from the factory, JVC products are strictly inspected to conform with the recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
Page 6 • Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original positions, Afterwards, perform the following tests and confirm the specified values in order to verify compliance with safety standards.
Page 7 SECTION 1 DISASSEMBLY 1.1 BEFORE ASSEMBLY AND DISASSEMBLY 1.1.4 Disconnection of connectors (Wires) 1.1.1 Precautions Connector Pull both ends of the connector in the arrow direction, re- 1. Be sure to remove the power supply unit prior to mount- move the lock and disconnect the flat wire. ing and soldering of parts.
Page 8 1.2 JIGS AND TOOLS REQUIRED FOR DISASSEMBLY, 1.3 DISASSEMBLY/ASSEMBLY OF CABINET PARTS ASSEMBLY AND ADJUSTMENT AND BOARD ASSEMBLY 1.2.1 Tools required for adjustments 1.3.1 Disassembly flow chart This flowchart indicates the disassembly step for the cabi- Torque driver YTU94088 YTU94088-003 net parts and board assembly in order to gain access to item(s) to be serviced.
Page 9 1.3.2 Disassembly method Note: Remove the parts marked in STEP CONN. Fig.No. POINT NOTE PART CONNECTOR Pin No. ⇔ COVER(ZOOM) Fig.1-3-1 (S1a),(S1b),2(L1a),2(L1b ) MAIN CN101 MONITOR CN761 ASSY CN106 ← → MIC MAIN — UPPER CASE ASSY Fig.1-3-2 4(S2a),3(S2b),(L2),(S2c) NOTE2 ⇔...
Page 10 Fig. 1-3-1 (DC JACK) NOTE (BOTTOM SIDE) (REAR SIDE) Fig. 1-3-2...
Page 11 NOTE NOTE Fig. 1-3-3 BRACKET (OP) ASSY Fig. 1-3-4...
Page 12 : 0.196 N m (2.0 kgf • • Fig. 1-3-5 NOTE Fig. 1-3-6...
Page 13 Fig. 1-3-7 SHIELD PLATE NOTE EJECT SW NOTE Fig. 1-3-8 Fig. 1-3-9...
Page 14 NOTE NOTE Fig. 1-3-10 PLATE (SPK) NOTE NOTE ∗ COVER (HINGE) ∗ ∗ : 0.147 N m (1.5 kgf • • Fig. 1-3-11...
Page 15 MONITOR ASSEMBLY Note: The shape of the monitor assembly varies by the size 3. Remove the screw (5), unplug the FPC from the connec- of the LCD screen. tor b , and then remove the LCD BL board assembly, DIF sheet and bracket (FRM2) in that order. For the 2.5”-type LCD, refer to Fig.
Page 16 E. VF ASSEMBLY (B/W) 1.5.1 Disassembly/assembly of E.VF ASSEMBLY (for the B/W VF) 5. Remove the screw (8) and the remove the CAP (VF). 1. Remove the EYE CUP. 6. Remove the FPC from the CASE A (VF) so that the CASE 2.
Page 17 1.6 DISASSEMBLY/ASSEMBLY OF 5OP BLOCK ASSEMBLY/CCD BOARD ASSEMBLY 1.6.1 Precautions 1.6.3 How to assemble CCD base assembly and CCD board assembly 1. Take care in handling the CCD image sensor, optical LPF and lens components when performing maintenance 1. Install the optical LPF with the spacer rubber attached etc., especially with regard to surface contamination, at- to its CCD side in the OP block assembly.
Page 18 1.7 EMERGENCY DISPLAY Whenever some abnormal signal is input to the syscon CPU, Example (in case of the error number E01): an error number (E01, as an example) is displayed on the LCD monitor or (in the electronic view finder). In every error status, such the message as shown below alternately appear over and over.
Page 19 1.8 SERVICE NOTE 1-13...
Page 20 SECTION 2 MECHANISM ADJUSTMENT 2.1 PRELIMINARY REMARKS ON ADJUSTMENT AND (3) The symbol (T or B)appearing in this column shows the REPAIR side which the objective part is mounted on. T =the upper side, B =the lower side 2.1.1 Precautions (4) Symbols appearing in this column indicate drawing 1.
Page 21 2.2 JIGS AND TOOLS REQUIRED FOR DISASSEMBLY, ASSEMBLY AND ADJUSTMENT 2.2.1 Tools required for adjustments 1. Torque driver Torque driver YTU94088 YTU94088-003 Be sure to use to fastening the mechanism and exterior parts because those parts must strictly be controlled for tightening torque.
Page 22 2.3 DISASSEMBLY/ASSEMBLY OF MECHANISM <SUB CAM GEAR> ASSEMBLY 2.3.1 General statement The mechanism should generally be disassembled/assem- bled in the EJECT mode (ASSEMBLY mode). (Refer to Fig. 2-3-1.) TOP VIEW BOTTOM VIEW However, when the mechanism is removed from the main body, it is set in the STOP mode.
Page 23 2.3.3 Mechanism timing chart MODE EJECT C IN SHORT FF STOP PLAY PARTS MAIN CAM (ø10.4) 31.7 45.6 49.5 74.04 129.5 156.6 169.2 211.5 280.3 SUB CAM (ø11) 43.1 46.8 122.5 148.1 ENCODER (ø10) 47.4 51.5 134.7 162.9 291.5 ROTARY ENCODER CAM SW SLIDE END...
Page 24 2.4 DISASSEMBLY/ASSEMBLY OF MECHANISM ASSEMBLY 2.4.1 Follow chart 1. Configuration Mechanism assembly Cassette housing assembly Slide deck assembly Main deck assembly Fig. 2-4-1 2. Procedures for disassembly Mechanism assembly Cassette housing assembly Slide deck assembly Main deck assembly Fig. 2-4-2...
Page 25 3. Disassembling procedure table PART NAME FIG. POINT NOTE REMARKS A Cassette housing assembly Fig. 2-4-5 3(S1),(L1a)-(L1d) 1a, 1b, 1c, 1d Adjustment Reel disk (SUP) assembly Fig. 2-4-6 (W2) 2a, 2b Reel disk (TU) assembly (W2) 2a, 2b Reel cover assembly (S2b),2(S2a),(W2) 2c, 2d Tension arm assembly...
Page 26 < TOP VIEW > 4b 11b 11a Main deck assembly Slide deck assembly 7b 7a 7d 7e 9c 3c 3b 7h 2b Fig. 2-4-3 < BOTTOM VIEW > Main deck assembly Slide deck assembly Fig. 2-4-4...
Page 27 2.4.2 Disassembly/assembly Note 1a: <STOP mode> Shift the mechanism mode 1. A Cassette housing assembly from the STOP mode to the EJECT mode. Cassette Note 1b: housing Reassemble the cassette (L1b) assembly housing assembly to the (S1) mechanism as the cancel lever is moved in the direc- tion of the arrow.
Page 28 3. 3a Tension arm assembly/ 3b Release guide assembly 3c Idler arm assembly/ 3d Guide arm assembly 3e Pinch roller arm assembly Note 3a: When removing the reel cover assembly, pay heed to re- lease guide assembly and guide arm assembly. For the (W3a) guide arm assembly is just inserted into the slide deck as- sembly from the upside and it is apt to come off after the...
Page 29 5. 5a Guide roller (S) assembly/ 5b Rail assembly Note 5a: When reassembling, insert the tip Guide roller of the guide roller with the coil (s) assembly spring put on it into the hole on the main deck. Tighten the guide roller by about 6 turns so that the Note 5a (P5)
Page 30 Note 7a: 7. 7a Loading brake assembly/ 7b Guide pin (S) Don’t remove these parts unreasonably. If they are removed 7c Pad arm assembly/ 7d Slide guide plate assembly for some reason, be very careful not to lose them. 7e Collar/ 7f Collar/ 7g Sub brake assembly 7h Control plate assembly Note 7b: When reinstalling the sub brake assembly, set the control...
Page 31 9. 9a Loading guide/ 9b Timing belt 9c Center gear assembly/ 9d Motor bracket assembly 9e Worm wheel/ 9f Gear holder Note 9a: Carefully handle the DEW sensor. (Don’t touch the sensor Note 9b Note 9a surface in particular.) Note 9b: When engaging the timing belt, make sure that it securely (S9) engages with the gears of both the center gear assembly and...
Page 32 11. 11a Catcher (T) assembly/ 11b Capstan motor 11c Charge arm assembly/ 11d Sub cam gear 11e PWB holder Note 11: The following figure shows how to put the charge arm as- sembly and sub cam gear assembly together. (S11) (S11) Note 11 (W11)
Page 33 2.4.3 List of procedures for disassembly Cassette housing assembly (P5) (L1b) (S9) (W5a) (S9) (W5b) (W5a) (W3b) (S1) (W5a) (W10b) (L1d) (L1a) (S4) (S4) (S4) (S1) (L1c) (S1) (S11) (W10a) (S10) (S11) (S10) (W10a) (S11) (S9) (S11) (W9) (W4) (P4b) (P4a) (S9) (W7)
Page 34 2.5 CHECKUP AND ADJUSTMENT OF MECHANISM PHASE <Connect gear> (Note 2) Set the connect gear so <Rotary encoder> that its locating hole meets Set the “I” of the rotary the hole on the main deck part at the tapped hole assembly.
Page 35 2.6 MECHANISM ADJUSTMENTS 2.6.1 Assembling slide deck assembly and main deck assembly œ Œ Fig. 2-6-1 Assembling procedure 1. Loosen the screw A. 2. Set the mechanism in the PLAY mode. (Refer to “2.3.2 Explanation of mechanism mode”.) 3. Press the end face B of the slide deck assembly (reel disk side) and the end face C of the main deck assem- bly (drum assembly side) with uniform force so that the two assemblies are tightly pressed to each other.
Page 36 2.6.2 Locating tension pole <PLAY mode> Fig. 2-6-2 Locating procedure 1. Enter the mechanism assembly into the PLAY mode. (Refer to “2.3.2 Explanation of mechanism mode”.) 2. When the “ ” part is positioned down, make sure that the part “a” of the tension arm assembly is located within the range of “b”.
Page 37 2.7 SERVICE NOTE Use the following chart to manage mechanism parts that are removed for disassembling the mechanism. Cassette housing assembly S1×3 Reel disk (SUP) assembly Reel cover assembly W2×1 Reel disk (TU) assembly W2×1 S2b×1 S2a×2 W2×1 Guide arm Tension arm Pinch roller arm Release guide...
Page 38 Slide deck assembly Loading Slide guide Guide pin Pad arm brake plate assembly assembly assembly W7×1 P7a×1 S7a×1 W7×1 P7b×1 S7b×1 Control Collar Collar Sub brake plate assembly assembly W7×1 P7c×1 W7×2 P7d×1 W6×1 Main deck assembly Slide lever Tension lever Brake control assembly assembly...
Page 39 2.8 COMPATIBILITY ADJUSTMENT 2.8.1 Jig connector cable connection Remove one screw (1) first and the cover (JIG) next. Jig connector cable (YTU93082G) CN105 Cover(JIG) JIG BOARD Fig. 2-8-1 Jig connector cable connection MAIN JIG BOARD CN105 (PIN NO.) (LABEL) AL_3VSYS AL_3VSYS DISCRI 10 DRST...
Page 40 2.8.2 Tape pattern check (1) Play back the compatibility adjustment tape. (2) While triggering the MAIN CN105-16PIN (HID1), ob- CN105 serve the waveform of CN105-15PIN (ENV_OUT). (ENV_OUT) (3) Confirm that the waveform is free from remarkable level-down, and entirely parallel and straight. Moreover, perform the following adjustment as re- CN105 quired.
Page 41 SECTION 3 ELECTRICAL ADJUSTMENT 3.1 PRECAUTION 3. Tools required for adjustments 1. Precaution Torque driver Both the camera and deck sections of this model needs a YTU94088 YTU94088-003 personal computer for adjustment except simple adjustment with potentiometers. If some of the following parts is replaced for repair or other reason, the repaired set must be adjusted with a personal computer.
Page 42 Torque driver Alignment tape Be sure to use to fastening the mechanism and exte- To be used for check and adjustment of interchange- rior parts because those parts must strictly be control- ability of the mechanism. led for tightening torque. 10.
Page 43 SECTION 5 PARTS LIST SAFETY PRECAUTION Parts identified by the symbol are critical for safety. Replace only with specified part numbers. REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ******************************...
Page 44 FINAL ASSEMBLY <M2> 146A MECHANISM 145A <M3> JUNCTION 145C 145B <05> RATING LABEL 158B MAIN <01> 158C 181 184 158A <04> OPTICAL BLOCK 251C SECTION 251C MONITOR <02> ELECTRONIC VIEWFINDER <M4> JACK <06> 101H 251C 251B 101B 125E 101C 200B 251A 251C 125E...
Page 45 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 46 BEWARE OF BOGUS PARTS MECHANISM ASSEMBLY <M3> Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine JVC parts be used. NOTE:The section marked in AA and BB indicate Classification Part No.
Page 47 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 48 ELECTRONIC VIEWFINDER ASSEMBLY <M4> 324B 324A 334 306 B/W VF <08> REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 49 MONITOR ASSEMBLY <M5> 501F 501A 501C 501E 501B 501D 501D LCD BL <03> 502A REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 50 ELECTRICAL PARTS LIST REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 51 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 52 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 53 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 54 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 55 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 56 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 57 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 58 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 59 REF No. PART No. PART NAME, DESCRIPTION REF No. PART No. PART NAME, DESCRIPTION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
Page 60 SCHEMATIC DIAGRAMS DIGITAL VIDEO CAMERA GR-DVL145EG CD-ROM No.SML200205 SPECIFICATIONS (The specifications shown pertain specifically to the model GR-DVL145EG/EK) Connectors Camcorder S-Video General : Y: 1 V (p-p), 75 Ω, analogue Output C: 0.29 V (p-p), 75 Ω, analogue Power supply : DC 11.0 V (Using AC Adapter) DC 7.2 V...
Page 61 SECTION 4 CHARTS AND DIAGRAMS 4. Voltage measurement NOTES OF SCHEMATIC DIAGRAM 1) Regulator (DC/DC CONV) circuits Safety precautions REC : Colour bar signal. The Components identified by the symbol : Alignment tape (Colour bar). critical for safety. For continued safety, replace safety —...
Page 62 CIRCUIT BOARD NOTES 1. Foil and Component sides 1) Foil side (B side) : Parts on the foil side seen from foil face (pattern face) are indicated. 2) Component side (A side) : Parts on the component side seen from component face (parts face) indicated.
Page 63 BOARD INTERCONNECTIONS J503 ∗ YTU94074-20 YTU94077-20 J501 CN5001 ∗ CN107 CAPSTAN MOTOR DRUM MOTOR LOADING MOTOR HEAD ROTARY NOTE ) : The number of patch cords ENCODER MECHA SENSOR are indicated by interconnected. R.E.SW JACK NC/GND (Page 4-35) (Page 4-37) CCD +15V CCD +15V CN502...
Page 64 MAIN IF SCHEMATIC DIAGRAM TO CAPSTAN MOTOR TO JUNCTION CN571 TO ZOOM UNIT TO MDA TO MDA TO D.CPU TO MDA TO MDA TO MDA TO SYSCON CN105 CN108 TO SYSCON VPPC VPPC Z_L_VCC TO REG REG_3V REG_3V TO OP.DRV ZOOM_LED ZOOM_LED TO D.CPU...
Page 65 SYSCON SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (SYSCON) EEPROM_CS R1020...
Page 66 NOTES : For the destination of each signal and further line connections that are cut off from D.CPU SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (D.CPU) TO REG L1401...
Page 67 NOTES : For the destination of each signal and further line connections that are cut off from MDA SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (MDA) TO D.CPU LD_REV...
Page 68 AUDIO SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (AUDIO) TO MAIN IF CN101...
Page 69 NOTES : For the destination of each signal and further line connections that are cut off from DVMAIN SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. MAIN (DVMAIN) C3041 C3040...
Page 70 NOTES : For the destination of each signal and further line connections that are cut off from PRE/REC SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. MAIN (PRE/REC) TO D.CPU...
Page 71 V OUT SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. MAIN (V OUT) L3701...
Page 72 NOTES : For the destination of each signal and further line connections that are cut off from 4.10 DSP SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (DSP) TO TG MAIN IF CN101...
Page 73 4.11 MONI IF SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (MONI IF) L4311 TO REG...
Page 74 NOTES : For the destination of each signal and further line connections that are cut off from 4.12 OP.DRV SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (OP.DRV) TO MAIN IF TO SYSCON...
Page 75 4.13 TG SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (TG) TL5501 TL5504...
Page 76 4.14 REG SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 1 MAIN (REG) TO MAIN IF CN105, SYSCON...
Page 77 4.15 MONITOR SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. TO B/W VF 0 2 MONITOR CN721...
Page 78 NOTES : For the destination of each signal and further line connections that are cut off from 4.16 LCD BL SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 3 LCD BL R751 C752...
Page 79 4.17 CCD SCHEMATIC DIAGRAM 4.18 JUNCTION SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS".
Page 80 4.19 JACK SCHEMATIC DIAGRAM NOTES : For the destination of each signal and further line connections that are cut off from this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. JACK R501 C501...
Page 81 NOTES : For the destination of each signal and further line connections that are cut off from 4.20 B/W VF SCHEMATIC DIAGRAM this diagram , refer to "4.1 BOARD INTERCONNECTIONS". When ordering parts , be sure to order according to the Part Number indicated in the Parts List. 0 8 B/W VF R7011 3.3k...
Page 82 4.21 MAIN CIRCUIT BOARD FOIL SIDE (B) 0 1 MAIN PWB YB10368-01-03 C4331 CN112 TL1003 TL1002 R1612 R1613 C1621 C1642 C1622 C4312 R1622 C1623 D1604 C4333 R1058 R1080 R1036 C1038 C1009 R1044 R1045 C1039 R1019 R1616 R4346 C1017 C1614 D1003 C1607 R1630 C1010...
Page 83 (1/2) COMPONENT PARTS LOCATION GUIDE <MAIN/YB10368-01-03> REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION CAPACITOR C2015 C3049 C4308 C4916 C6226 IC4901 C2016 C3050 C4309 C4917 C6227 IC5501 C1003 C2017 C3051 C4310 C4918 C6228 IC6001 C1004 C2018 C3052...
Page 84 (2/2) COMPONENT PARTS LOCATION GUIDE <MAIN/YB10368-01-03> REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION REF.NO. LOCATION Q3702 R1082 R2105 R3509 R4379 R6115 TL1024 Q4304 R1083 R2106 R3510 R4380 R6116 TL1025 Q4305 R1090 R2107 R3511 R4381 R6117 TL1026 Q4306 R1091...
Page 85 COMPONENT SIDE (A) 0 1 MAIN PWB YB10368-01-03 R4616 CN109 R4615 Q4602 CN113 R1095 R4620 CN110 C4606 C4611 R4625 R4608 R4622 R4618 R1017 R1097 R4607 R4606 C4612 R4619 C4918 R1096 R4905 R1094 Q1012 C4914 C3502 R1093 R4911 R1091 Q1011 L4901 R4903 R4902 IC4602...
Page 86 4.22 MONITOR CIRCUIT BOARD FOIL SIDE (B) COMPONENT SIDE (A) 0 2 MONITOR PWB 0 2 MONITOR PWB YB10369-01-01 YB10369-01-01 ZP1-4 ZP3-6 TL7602 TL7606 ZP3-13 R7633 C7631 TL7601 ZP1-6 C7634 R7665 Q7609 ZP4-33 ZP4-32 ZP4-18 C7622 TL7607 C7626 C7603 R7646 C7623 ZP4-31 R7644...
Page 87 4.23 LCD BL CIRCUIT BOARD FOIL SIDE (B) COMPONENT SIDE (A) 0 3 LCD BL PWB 0 3 LCD BL PWB YB20929-01-01 YB20929-01-01 C7505P C7505 Q7501 IC7501 C7506 R7501 R7503 L7503 Q7502 Q7505 F7501 R7511 C7504 R7502 C7508 Q7503 Q7506 CN751 R7509 Q7504...
Page 88 4.24 CCD, VF AND JUNCTION CIRCUIT BOARDS - CCD - - JUNCTION - FOIL SIDE (B) COMPONENT SIDE (A) FOIL SIDE (B) COMPONENT SIDE (A) 0 4 CCD PWB 0 4 CCD PWB 0 5 JUNCTION PWB 0 5 JUNCTION PWB YB20924 YB20924 YB20925-01-01...
Page 89 4.25 JACK CIRCUIT BOARD FOIL SIDE (B) COMPONENT SIDE (A) Q501 C508 R511 IC502 C505 C506 L501 R513 C514 D502 D504 C504 R509 L503 D503 R506 R504 IC501 TL503 R508 0 6 JACK PWB 0 6 JACK PWB R505 R502 R503 YB20925-01-01 YB20925-01-01...
Page 90 4.26 VOLTAGE CHARTS <SYSCON> <D.CPU> <MONI IF> <CCD> <LCD BL> MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE PLAY PLAY PLAY PLAY PLAY PLAY PLAY PLAY PLAY PLAY PIN NO. PIN NO. PIN NO. PIN NO. PIN NO.
Page 91 4.27 POWER SYSTEM BLOCK DIAGRAM MAIN REAR UNIT CN104 BATT_ BATT_ BATT. TERM OP BLOCK REG_1.8V CN107 CN5001 REG_1.8V CCD_15V Q5001 REG_3V CCD_15V REG_15V IC4301 ADP_DC IN IC4302 ADP_H REG-CCD IC5501 Q6208 F6101 L6102 IC5001 ADP_DC CCD-7.0V DRUM_PWR DRUM ADP_DC IC4202 Q6210 REG_4.8V...
Page 92 4.28 VIDEO SYSTEM BLOCK DIAGRAM IC4301 (DSP) MAIN IC5001 IC4201(CDS/AGC/AD) Q5001 DYI0 (CCD) CN5001 CN107 AD0~AD9 ADIN9 DYI3 VOUT CDSIN KIZU BLOCK ADIN0 CONV DCI0 DCI3 DVMAIN CLK27 CLK18 DYO0 CLK13 DYO3 XAVD VDTG DCO0 XAHD HDTG EEP_DT_OUT VGAT IC1003 LMFO DCO3 EEP_IN...
Page 93 IC3001(DVMAIN) IC3501 MAIN HID3 TO D.CPU HID3 YSO0 VIDEO I/F COMPRESS OUTER ECC INNER ECC PB_H YSO3 RECH (VBID DET (DCT,VLC (ENC/DET) (SUB/AUX) (ENC/DEC) FSPLLCTL REC_H PWMAUDIO RAM) VLD WORK RECCTL RECCTL BRSO0 RAM) HID1 RECDATA HID1 BRSO3 FORMATTER RECDATA RECCLK TO DSP (Formatting...
Page 94 4.29 REGULATOR SYSTEM BLOCK DIAGRAM MAIN(REG) REAR UNIT CN104 BATT+ BATT+ BATT.TERM ADP_DC ADP_DC ADP_DC Q6002(1/2) R6004 R6001 POWER OFF:ON R6002 ADP_DC IN BATT_CHK IC6001 BATT DC DET F6101 T_BATT at POWER OFF T_BATT M_UNREG 1 DET:L Q6208, IC6101 L6101 L6102 ADP_H L6206, C6215...
Page 95 VICTOR COMPANY OF JAPAN, LIMITED S40894 VIDEO DIVISION Printed in Japan...
