Activating/Deactivating Cooking Zones and
Adjusting Power Levels
To activate the cooking zones:
� Activate the desired zone by pressing the
button.
� Place your finger on the slider of the zone and gently slide it
horizontally to the right to increase the power level or, to the
left to decrease the power level.
� You will notice that the slider segments will turn to high
luminosity based on the selected power level and the
corresponding display will show the power level selected
(ranging 1 to 18).
� The "P" button can be used to select the Power Boost to
quickly boil water.
To deactivate the cooking zones:
� Press the zone ON/OFF button.
NOTE: Water spillage, food overflow and/or object positioned on
the control panel buttons can mimic one's finger, which can
activate or deactivate any of the cooktop buttons. If such presence
is not removed within 8 seconds, OFF is displayed on the zone
and the cooktop will automatically switch off while producing a
sound.
Control Panel Lock
The control panel lock function is designed to lock the cooktop,
thus avoiding changing any setting. This function is
recommended during cleaning of the glass. To activate the control
panel lock, press and hold the
button will switch to high luminosity, and a light above the symbol
will indicate that this function has been activated. To unlock the
cooktop, press again the button for 3 seconds. You can only
deactivate it if the cooktop is ON.
NOTE: When the control panel lock function is active, no other
function can be activated. If you try to interact with the product, the
button will blink. You can still switch the product on and off.
Residual Heat
If "Hot" appears on the display of a cooking zone, this means that
the cooking zone is hot. The indicator might light up even if the
zone has not been used, but has been heated due to the adjacent
zones' use or because a hot pot has been placed on it. When the
cooking zone has cooled down, the "Hot" disappears.
Pot Incorrectly Positioned or Missing
The symbol appears if the pot is not suitable for induction cooking,
is not positioned correctly or is not of an appropriate size for the
cooking zone selected. If no pot is detected within 30 seconds, the
cooking zone will switch off.
Setting Menu: Changing the basic settings
Once you have connected the device to the mains power supply,
you will be able to change the default settings ONLY within the
first 60 seconds the machine has been powered up, following
these instructions:
1. Press the cooktop ON/OFF button and turn on the cooktop.
LOCK
2. Press and hold the button for 6 seconds to enter the
3 sec
Setting Menu.
3. After 3 seconds the product will sound, keep the button
pressed until the Setting Menu is showing up.
4. The rear-left display will show one of the setting types
indicated in the table below. The front-left display will show the
current setting.
5. Use the rear-left up or down arrows to change the setting type.
6. Once the display will visualize the setting type you wish to
change, use the front-left up or down arrows to change the
setting value.
zone ON/OFF
P
LOCK
button for 3 seconds. The
3 sec
7. Press the cooktop ON/OFF button to confirm.
NOTE: Without this confirmation, the cooktop will exit from the
setting menu and return to the previous values within 30 seconds.
Rear-
Setting
Left
Order
Type
display
Power
1 PL
Limitation
Temperature
2 tP
F/C
3 Audio Tone Aud
4 Demo Mode dE
Power Limitation
At the time of purchase, the cooktop is set to the maximum power.
NOTE: Depending on the power limitation level selected, some of
the functions could be automatically limited to keep the selected
limit from being exceeded. Example: if you set the Power
Limitation setting of your cooktop to 4 kW, it will not be possible to
activate the Power Boost on more than one zone at a time.
Functions
Power Levels
This cooktop offers 18 power levels for a more refined control of
power while cooking. The cooking table below offers cooking tips
for each power level. The actual power delivered depends on the
size of the cooking zone as well as the cookware.

POWER LEVEL

COOKING TIPS

Bring the water to a boil as quickly as
possible. Do not use an empty pan or
Power Boost
oil/butter.
Bring the water to a boil, deep fry frozen
17–18
products.
Maintain a lively boil, quick-sear, blister,
15–16
stir-fry, brown.
Maintain a gentle boil, preheat, grill (for
a long period of time), stir-fry, sauté,
10–14
caramelise, brown, pancakes.
Simmer, Stew, Thicken, Slow Cook.
5–9
Keep warm, Defrost.
3–4
Melting, Creaming (risotto)
1–2
Cooktop is in stand-by or off mode
(possible end-of-cooking residual heat,
Zero power (OFF)
indicated by "Hot").
Power Boost "P"
Boost is a special mode with a higher power than level 18, that
allows water to boil the fastest. This mode can be maintained for a
maximum time of 10 minutes, depending on the zone used (refer
to table below). After this time the power will be automatically
reduced to level 18.
IMPORTANT: Do not use with an empty pan or oil/butter. This
function is intended for boiling water.
NOTE: If you set one cooking zone to Power Boost and then
activate another zone, the first one might be reduced to level 18,
to allow the second one to be used. The second cooking zone
may as well be limited based on the remaining power available.
Front-Left
Possible
display
Values
(Default)
4, 6, 7.4, 9,
11 kW
11 kW
°F °F/°C
On On/Off
Off Off/On
3
