Prepare the components
Chassis
Power supply unit
NOTE: The components listed above are recommendations, please prepare components according to your needs.
Install key components
•
Install the CPU
OR
NOTE: Do not remove the PnP cap before the CPU is properly installed.
Please refer to the manual(s) for more information:
•
Install the Memory
NOTE: Please refer to the manual(s) for more information:
CPU
CPU Cooler
Graphics card
OR
Motherboard
Memory configurations
A1
1 DIMM
2 DIMMs
P
4 DIMMs
Motherboard
Memory
SATA device
Thermal paste
CPU installation
DIMM
A2
1st
B1
B2
1st
P
P
P
P
P
P
M.2 SSD
3
