TECHNICAL DATA BROCHURE ZTR
Model 361
IMPORTANT - READ OPERATOR'S MANUAL BEFORE OPERATING OR MAKING ADJUSTMENTS

SEAT ADJUSTMENT

1. Pull or lift body retention latch P/N 39,34 from
transaxle backing plate, raise and push body
and seat assembly forward.
2. Loosen four seat adjustment knobs
P/N 1849 and slide seat forward or backward to
desired position.
3.
Re-tighten seat adjustment knobs P/N 1849.
DO NOT operate mower without seat
adjustment knobs properly tightened.
4. Close upper body and push retention latch P/N
3934 over transaxle backing plate.
